Telair ICEBERG SPLIT 7000 - Page 12

- 12 -
GB
SPLITSPLIT
SPLITSPLIT
SPLIT 7000
8
1
2
3
4
Fit the through bushes into the socket and lock
them in place using the plastic nuts provided.
Let the supply cable out locking the through bush in
place on the steel plate socket Fig. 8 Ref. (5). Put
the lids back on, fastening them carefully Fig. 8 Ref.
(6).
5
6
6
6
A damaged input cable
should only be replaced by the
manufacturer or its authorised after-sale
service.personnel.
