Fig. 2: Front Panel
The following table provides information on each connector, as well as a description:
Front panel elements
Item Description
A Power source connection (PSU).
Refer to External Power Source on page 13 for more information on Power con-
nection and Power Supply on page 33 for power specifications applicable to the
WWAN Enabler device.
B LAN1/POE 2.5 Gigabit Ethernet.
Refer to PoE on page 13 for more information on PoE connection
For more information on the LAN interface, refer to:
- LAN Connection on page 14
- LAN Connector on page 26
- LAN Interface on page 27
C LAN2. 2.5 Gigabit Ethernet.
For more information on the LAN interface, refer to:
- LAN Connection on page 14
- LAN Connector on page 26
- LAN Interface on page 27
Teldat S.A.
3 Components and Power Supply
WWAN Enabler 7
