Board Guide TCC8900 DEMO BOARD PIN DESCRIPTION
Preliminary 1-4
z Interface Connector Description of CPU Board
-JR1: LVDS Interface Connector
-JR2: Board to Board Connector0 for Main and Module Interface
-JR3: Board to Board Connector1 for Main and Module Interface
z Power Header Pin Description of CPU Board
-JP1: HDMI_PWR
-JP2: LVDS_PWR
-JP3: DRAM_PWR
z Other Pins of CPU Board
-JC1: HDMI Connector
-JC2: USB OTG Connector
-JC3: SATA Connector
-JC4: USB Host Connector
z Interface Header Pin and Connector Description of Main Board
-JR1: Board to Board Connector0 for Main and Module Interface
-JR2: Board to Board Connector1 for Main and Module Interface
-JR8: External NAND and NOR Interface
-JR9: External NAND and NOR Interface
-JR10: ATAP Interface
-JR11: LCD Interface
-JR12: LVDS Inverter Interface
-JR13: LVDS Touch Screen Interface
-JR14: External CODEC Interface
-JR15: External CODEC Interface
-JR16: iPOD Interface
-JR17: CAB Bus Interface
-JR18: Ethernet Interface
-JR19: Ethernet Interface
-JR21: DXB Interface
-JR22: GPS Interface
-JR23: GPS Interface
-JR24: Power Interface
-JR25: Power Interface
z Power Header Pin Description of Main Board
-JP2: RTC_PWR
-JP3: CORE_PWR
-JP4: PLL_PWR
-JP5: USB12_PWR
-JP6: SATA1_PWR
-JP7: SATA2_PWR
-JP8: SATAPLL_PWR
-JP9: HDMI_PWR
-JP10: HDMIPLL1_PWR
-JP11: HDMIPLL2_PWR
-JP12: MEMQ_PWR
-JP13: MEMZQ_PWR
-JP14: GPIOA_PWR
-JP15: GPIOB_PWR
