Telefunken TF-RS9200 User Manual

- 29 -
Specications
GENERAL
• Adaptor Input Voltage : 100-240V~ 50 Hz
• Adaptor Output Voltage : 12V DC
• Input Frequency : 950 - 2150 MHz
• Maximum Power Consumption : 17W
• Operating temperature : 5ºC - +40ºC
• Storage temperature : -20ºC +70ºC
• Humidity : 25 to 75 % rel
• Physical Dimensions : 110 x 82,20 x 22,60 mm
• Weight : 0,29 kg
HARDWARE CONFIGURATION
• Main Processor : M-STAR MSD7819
• Flash Memory : 16 Mbyte
• DDRAM : 128 Mbyte
Remote Control
Operating Distance: 7m Max.
Batteries : 2x1.5V (R-03/AAA)
Digital Capabilites
Transmission Standarts:
DVB-S, DVB-S2, MPEG2/HD ,MPEG4
Demodulation:
QPSK, DVB-S 1-45Msym/s
QPSK, DVB-S2 1-45Msym/s
8PSK 1-45Msym/s
FEC Modes:
• QPSK, DVB-S 1/2, 2/3, 3/4, 5/6, 7/8.
• QPSK, DVB-S2 1/2, 3/5, 2/3, 3/4, 4/5, 5/6, 8/9, 9/10.
• 8PSK 3/5, 2/3, 3/4, 4/5, 5/6, 8/9, 9/10.
Video:
• HD MPEG-4
• Aspect ratio; 4:3, 16:9
• Mpeg 1/2/4, H.264 ve VC-1
Audio:
• For all MPEG levels for layer I / II
• Sampling frequencies supported are 32 kHz, 44.1
kHz or 48 kHz.
• Output can be chosen as STEREO, LEFT or RIGHT
only (on both outputs).This is useful for dual mono
channels in order to select the correct sound track.
• Wide dynamic range (16-bit resolution)
• Mpeg-1, Mpeg-2 (Layer I/II), MP3, AC-3
LNB POWER SUPPLY
• Vertical : 13/14 Volt
• Horizontal : 17/18 Volt
• Max. Output Current: 300mA (Short-circuit protected)
• 22 kHz Tone : Frequency 22KHz ± 2 KHz
: Amplitude 0.6 Vpp ± 0.2 Vpp
USB POWER SUPPLY
5V @ 500mA max
Front Panel
Indicator
4 digit indicator is 7 segments.
Audio/Video & Data Input/
Output
HDMI Output (Audio and Video)
Digital Audio Output (Audio)
Scart Output (Audio and Video)
Conformity Information
The satellite receiver complies with the following
standards and norms:
In regard to the conformity with fundamental
requirements and relevant regulations, this device
complies with EMC Directive 2004/108/EC as well as
with Directive 2006/95/EC for Low Voltage Equipment.
Ecodesign requirements for energy-related products
(Directive 2009/125/EC according to Implementing
Regulation No. 642/2009).
EN 55013:2001+A1:2003+A2:2006
EN 55022:2010/AC:2011 – Class B
EN 61000-3-2:2006+A1:2009+A2:2009
EN 61000-3-3:2008
EN 5020:2007+A11:2011
EN 55024:2010
IEC60065:2001+A1:2005+A2:2010
EN60065:2002+A1:2006+A11:2008+A2:2010
+A12:2011
WARNING
This is a Class A product. Using this
product in a domestic environment may
lead to radio interferences. In such a
case, the user might possibly need to take
relevant measures.
