Eclipse 8/ 16/ 32 Series - Engineer Programming Manual
50
PGM 01
DEACT. TM
ADDRESS
3017
OPERATION
317 + 01
TEXT MENU
5. OUTPUTS – 2. PGMs – 01. PGM – 7. DEACT TIMER
Deactivation timer for PGM 01 – setting a time for deactivation the event programmed at
address 3013
A deactivation timer for the programmed at ADDRESS 3013 event is set at this address. The state
of PGM 01 will restore after the set time is over. The engineer enters time in range 000 – 255 as the
time unit (seconds or minutes) depends on the settings at ADDRESS 3011, option 5. By default, the
programmed time unit is in seconds.
Default setting: [000]
PGM 01
DELAY
ADDRESS
3019
OPERATION
319 + 01
TEXT MENU
5. OUTPUTS – 2. PGMs – 01. PGM – 8. DELAY
Time delay for activation of PGM 01
A time delay for the programmed at ADDRESS 3013 event is set at this address. The activation of
PGM 01 will be delayed in time. The engineer enters time in range 000 – 255 as the time unit
(seconds or minutes) depends on the settings at ADDRESS 3011, option 3. By default, the
programmed time unit is in seconds.
Default setting: [000]
TABLE 1. Events Type
In case of setting of activation event and missing deactivation event (0), the PGM output restores in the way
described for the activation event!
ADDRESS:
3xx3 - Activation
ADDRESS:
3xx4 – Set Parameter 1
ADDRESS:
3xx5 – Set Parameter 2
00
The output is not used
Event No
ZONE Event - Description
PARAMETERS 1
PARAMETERS 2
01
ZONE OPEN
Zone Open
Activated on “OR” function (if at least one of
the set area numbers is open the PGM is
activated)
Deactivated on “AND” function (when all of
the set area numbers are closed the PGM
is restored)
Enter zone number “FROM”
Enter zone number “TO”
“00” – not used, operates only
“FROM”
02
Not used
-
-
03
ZONE
BYPASS
Zone Bypassing
Activated on “OR” function (if at least one of
the set area numbers is bypassed the PGM
is activated, with no sense of the way of
bypassing)
Deactivated on “AND” function (when all of
the set area numbers are not bypassed the
PGM is restored)
Enter zone number “FROM”
Enter zone number “TO”
“00” – not used, operates only
“FROM”
04-07
Not used
-
-
08
ZONE
TAMPER
Zone Tamper
Activated on “OR” function (if at least one of
the set area numbers is with open tamper
the PGM is activated)
Deactivated on “AND” function (when all of
the set area numbers are with closed
tamper the PGM is restored)
Enter zone number “FROM”
Enter zone number “TO”
“00” – not used, operates only
“FROM”
09-11
Not used
-
-
