Eclipse 8/ 16/ 32 Series - Engineer Programming Manual
49
5. OUTPUTS – 2. PGMs – 01. PGM – 3. AREAS
Association of Areas to PGM 01
According the system configuration the engineer associates one or several AREA numbers for
operation with PGM 01. To select an AREA press the digit button corresponding to its number. The
next pressing of the same button will deselect the AREA.
To select all areas press button “0” – the button alternatively switches over all enabled / all disabled
state.
The PGM will be inactive if there are no associated areas to it!
Default setting: AREA 1
At ADDRESSES 3013, 3014 and 3015 is set a number of an activation event for PGM 01 output and supplementary
parameters depending on the set event – for zones, areas, users, troubles or other special ones.
The programmed activation events make sense when the PGM 01 output is programmed as general output – at
ADDRESS 3011 is set “” – see the description of the option above.
The types of the activation events are described in details in Table 1.
5. OUTPUTS – 2. PGMs – 01. PGM – 4. ACTIVATION
Programming a number of activation event for PGM 01
Choose a number of an activation event according the Table 1. Use the digit buttons to enter the
event number. Press the ENTER to confirm.
The default content of the next two addresses (3014 and 3015) depends on the set number at this
address.
Default setting: 27 – Alarm in Area
5. OUTPUTS – 2. PGMs – 01. PGM – 5. PARAM 1
Programming of Parameters 1 of the activation event for PGM 01
The type of Parameters 1 depends on the set activation event at ADDRESS 3013 – see Table 1 for
details.
Default setting: All parameters for event 27
5. OUTPUTS – 2. PGMs – 01. PGM – 6. PARAM 2
Programming of Parameters 2 of the activation event for PGM 01
The type of Parameters 2 depends on the set activation event at ADDRESS 3013 – see Table 1 for
details.
Default setting: n.a.
