LED Description
Orange, blinking The
WAP
is updating.
Orange, steady The system is updating.
RF Signal Pattern
Three antennas positioned in the WAP generate and receive an RF signal in a specific pattern. They
maximize the number of signal paths sent in the air, and provide an omnidirectional radiation pattern,
ensuring a range of 40 meter, or 130 feet.
Figure 1-9 Omnidirectional RF signal patterns
WIRELESS ACCESS POINT (WAP) 25
