Telewave, Inc.

Model 44A/AP

Page 9

5 OPERATION

Unpacking

5.01 After the Model 44A/AP Wattmeter arrives, examine the shipping

container for visible loss or damage. Carefully unpack the watt-

meter and examine the exterior for damage.

IMPORTANT

The Model 44A/AP Wattmeter is carefully tested, inspected, and

packed before leaving the Telewave factory. Claims for loss or

damage sustained in transit should be made upon the carrier,

NOT TO Telewave, Inc., as follows:

(1) Visible Loss or Damage - Any evidence must be noted on

the freight bill or express delivery sheet. The form required

to ﬁ le such a claim will be supplied by the carrier.

(2) Concealed Loss or Damage - This damage does not be-

come evident until after the wattmeter is unpacked. When

the damage is discovered, make a written request for in-

spection by the carrier’s agent within ﬁ fteen (15) days of

the delivery date. File a claim with the carrier.

RF Connections

5.02 The following procedure will assist the user in preparation for

making an RF power measurement. Refer to Figure 2-1.

Step Procedure

1 Remove the RF power from the transmission line.
