BlueMod+S50 Hardware User Guide
1VV0301505 Rev. 1 Page 10 of 53 2018-03-02
3. GENERAL PRODUCT DESCRIPTION
Feature Summary
• Supports Bluetooth low energy
• Qualified Bluetooth V5.0 Single Mode LE
• Supports 2 Msym/s PHY for LE
• Arm® CortexTM-M4F core for embedded profiles or application software
• RF output power -20 up to +4dBm
• RF output power -40dBm in Whisper Mode
• Supply voltage range 1,7V to 3,6V
• Internal crystal oscillator (32 MHz)
• LGA Surface Mount type. BlueMod+S50: 17 x 10 x 2.6 mm
3
• Pin compatible to Telit BlueMod family +S, +S42, +S42M and +SR
• Flexible Power Management
• NFC peripheral communication signal interface type A with 106 kbps bit rate
• High-speed UART interface
• I2C Master
• SPI Master/Slave interface
• Up to 19 digital IO’s for individual usage by embedded software
• Up to 8 analog inputs for individual usage by embedded software
• 8/9/10/12bit ADC
• Low power comparator
• Real Time Counter
• 128-bit AES encryption
• CE certified
• Shielded to be compliant to optional FCC full modular approval
• Manufactured in conformance with RoHS2
• Operating temperature -40 ... +85 °C
• Weight: 0,7 g
