BlueMod+S50 Hardware User Guide
1VV0301505 Rev. 1 Page 9 of 53 2018-03-02
2. OVERVIEW
This document provides information how the BlueMod+S50 can be integrated into customer
systems. It addresses hardware specifications of the BlueMod+S50 and requirements of
the hardware environments for the BlueMod+S50.
The term BlueMod+S50 is used as an abreviation and refers to both,
the BlueMod+S50/AI and the BlueMod+S50/AP.
If information is related to dedicated versions, the whole product
name is used.
The BlueMod+S50 is delivered in two different hardware versions:
• BlueMod+S50/AI: with integrated bluetooth antenna
• BlueMod+S50/AP: without integrated bluetooth antenna and with a 50Ω rf
connection on pin.
The integration of the BlueMod+S50 bluetooth module within user
application shall be done according to the design rules described in
this manual.
The information presented in this document is believed to be accurate and reliable.
However, no responsibility is assumed by Telit Communications S.p.A. for its use, nor any
infringement of patents or other rights of third parties which may result from its use. No
license is granted by implication or otherwise under any patent rights of Telit
Communications S.p.A. other than for circuitry embodied in Telit products. This document
is subject to change without notice.
