Telit Wireless Solutions BlueMod+S50/AI User Manual

BlueMod+S50 Hardware User Guide
1VV0301505 Rev. 1 Page 12 of 53 2018-03-02
Block Diagram
nRF52832
VSUP
BlueMod+S50/AI
RESET
I2C
UART
SPI
1 2
up to 7
3
GND
3.0V
32MHz
opt. 32kHz
Serial Wire Debug
onboard
antenna
2
GPIO
up to 19
Analog In
up to 6
NFC-Antenna
2
32,768kHz
optional
Figure 1: BlueMod+S50/AI Block Diagram
nRF52832
VSUP
BlueMod+S50/AP
RESET
I2C
UART
SPI
1 2
up to 7
3
GND
3.0V
32MHz
opt. 32kHz
Serial Wire Debug
2
GPIO
up to 19
Analog In
up to 6
NFC-Antenna
2
32,768kHz
optional
BT-Antenna
1
Figure 2: BlueMod+S50/AP Block Diagram
