8. Logic Level Specifications
Where not specifically stated, all digital interface circuits work at 1.8V CMOS logic levels. The
following table shows the logic level specifications used in the GE910 interface circuits:
Absolute Maximum Ratings -Not Functional
Parameter Min Max
Input level on any digital pin
(CMOS 1.8) when ON
-0.3V
+2.1V
Operating Range - Interface levels (1.8V CMOS)
Level Min Max
Input high level
1.5V 1.9V
Input low level
0V 0.35V
Output high level
1.6V 1.9V
Output low level
0V 0.2V
Current characteristics
Level Typical
Output Current 1mA
Input Current 1uA
