L-C filtering for LOW impedance load.
R-C filtering for HIGH impedance load.
EAR+
EAR-
TELIT MODULE
-
+
OUTPUTDAC
GND
EAR+
EAR-
TELIT MODULE
-
+
OUTPUT
DAC
GND
HiZ CIRCUITRY
