Figure 4-3 MultiTech Interface Board - Bottom View
For detailed description, refer LE910Cx Multi Technology Interface Board TLB – HW User
Guide.
4.3. WE866Cx M.2 Card
The M.2 card is designed to interface the Telit LE910Cx module family on an IFBD with the
Telit Generic Evaluation Board (EVB) thus forming a complete Development Kit of
LE910Cx.
The following image shows the top view of the M.2 card mounted with a WE866Cx module.
Figure 4-4 WE866Cx M.2 Card
