M.2 Overview
This section will provide an overview of the standard features of a M.2 Card, information on
the various SKUs of 2G/3G/4G (LTE) M.2 modules along with a respective functional block
diagram of each SKU.
2.1
SKUs - 2G/3G/LTE M.2 Modules
There are five different M.2 modules available in the M.2 Card Type 3042 form factor:
• HN930 - HSPA+
• LN930-AP - APAC LTE
• LN930 - LTE
A comparison of the features, RF band Support, and data rates for the various M.2 modules is
shown in Table 1 through Table 3
