Table 34 Conducted Transmit Power – LTE
HDPA+ / LTE LN930
Parameter
Condition
Requirement
Conducted Transmit Power
1
E-UTRA class 3
23 dBm + 0.5/- 1 db
LN930-AP (APAC SKU only)
Parameter
Condition
Requirement
Conducted Transmit Power
1
E_UTRA class 3
22.5 dBm + 0.5 /- 1 db
2
Conducted transmit power as measured at the WWAN M.2 RF main antenna connector.
9.6
Receiver Sensitivity
The reference sensitivity power level is the minimum mean power applied to both the WWAN
M.2 antenna ports at which the throughput shall meet or exceed the requirements for the
specified reference measurement channel.
Condition: Calibration voltage = 3.3V, 25C shielded room
Table 35 Rx Sensitivity - GSM
Band Condition Min Rx Sensitivity Limit (dBm)
GSM850 GMSK -110
GSM900 GMSK -109
GSM1800 GMSK -109
GSM1900 GMSK -106
