• Update setting for Pin 21 on the host interface. This signal is not connected.
• Updated pin names of pins 1, 21, 69, and 75 in Table 4 and Table 19 to
simply reflect HW Configuration use.
• Updated Table 24 to indicate configuration pins 1, 69, and 75 are tied to
GND.
• Rename section 3.6 Coexistence Interface to In-Device Coexistence
Interface. Additional information on the Inter-device coexistence support was added.
• Updated section 4.1.3 System Trace Tool Section.
• Updated Figure 5 – RF Engine for WW SKU.
• Add further information USB LPM to USB section
• Added information on Seamless Roaming & Wifi Off-load – SIM_EAP,
SIM-AKA under Other Requirements
• Added information on Antenna Design Guidelines under Other
Updated section 3.5 and 3.4.5
HN930-DC product was removed from portfolio
Main & Diversity antenna positions have been swapped.
• Updated documentation accordingly, Figure 6 and Figure 10.
• Updated WWAN M.2 Mechanical drawings, Figure 14 through Figure 17.
• Updated Card_power_ON_OFF description for UltraBook in Table 9.
• Updated comments in Table 15 regarding the DPR#/SAR signal.
• Updated SIM DTECTED signal to indicate an external pull-up.
• Updated Platform Block Diagrams to show DPR# signal is connected to an
EINT pin (not GPIO) on XGOLD.
•
Identified Audio Signals on host interface in Table 4. Previously these were
simply defined as Reserved.
• Updated VBAT requirements in Table 24 and Table 25.
• Regulation section was updated
• Adding support for UMTS Band 6 to M.2 APAC SKU (see Table 2).
•
Updated 3G RF Band support for APAC Module, supported bands are 1, 8,
11, and 19. (see Table 2)
• Added Measured Values for 2G/3G Rx Sensitivity Table 31 and Table 32.
• Update Measured Value and changed header name in Rx Sensitivity LTE
Table 33
• Modified supply voltage lower spec for Ultra book in Table 24.
• Update Table 4, Table 6, Table 26 voltage levels for USB and SIM pins.
• Added LTE conditions and added Table 33.
• Added SSIC to ICP interface. Updated RESET signal definition. Updated
Antenna figures.
• Updated Conducted Transmit Power requirements, Table 32.
• Section 2.2, Table 4
• Changed UIM signals pins 30, 32, 34, 36
• Replaced dash with underscore in signal names.
• Changed supply voltage for Antenna Tuning Signal
(ANTCTL*) from (1.7 V – 2.6 V) to 1.8 V.
• Section 3.5, Table 20 changed supply voltage for Antenna Tuning Signals
(ANTCTL*) from (1.7 V – 2.6 V) to 1.8 V.
• Section 3.11, Table 25 correction to both no connect pins and key slot pins.
• Section 8.2, Table 27
o Changed the max voltage to 3.0 V for WAKE_WWAN# signal
o Changed Typ voltage and max voltage for the Antenna Tuning
Signals to 0/1.8 V and 2.3 V respectfully
