LN930 M.2 Hardware User Guide
1VV0301078 Rev.10 – 2015-11-11
Reproduction forbidden without written authorization from Telit Communications S.p.A. - All Rights Reserved. Page 65 of 88
UMTS FTP, Cat 14, QAM64
(M.2 DC-HSDPA+)
Band 1 771 mW
UMTS FTP, Cat 14, QAM64
(M.2 HSDPA+)
Band 1 813 mW
Standby Power
UMTS Stand-by current, DRX7, 16NB cells - 6 mW
UMTS Stand-by current, DRX7, 16NB cells (HN930)
-
6.6 mW
Table 31
GSM Power Consumption
GSM Use Case
Band
Transmit Power
2UL, 1DL, PCL10 (*) GPRS 900 475 mW
2UL, 1DL, PCL5 (*) GPRS900 1482 mW
Standby Power
GSM Stand-by, DRX5, 16NB cells - 6 mW
GSM Stand-by, DRX5, 16NB cells (£) - 6.88 mW
(*) Applicable to modules: LN930, LN930-AP, HN930
(£) Applicable to module: HN930 (XMM™ 6260 based)
