LN930 M.2 Hardware User Guide
1VV0301078 Rev.10 – 2015-11-11
Reproduction forbidden without written authorization from Telit Communications S.p.A. - All Rights Reserved. Page 28 of 88
3.1.2
USB Super-speed IC (Reserved)
The USB Super-speed IC (USB SSIC) solution is not supported by the WWAN M.2 modules
presented in this Product Description. It is set aside for future development. These signals
should be left un-connected on the host.
Table 6 USB SSIC – ICP Interface
Signal Name
Description
Pin
Direction
(WWAN)
Operating
Voltage
Range
SSIC_RXN USB SSIC Receiver Signal N 29 O
Per SSIC
specification
SSIC_RXP USB SSIC Receiver Signal P 31 O
SSIC_TXN USB SSIC Transmitter Signal N 35 I
SSIC_TXP USB SSIC Transmitter Signal P 37 I
