LN930 M.2 Hardware User Guide
1VV0301078 Rev.10 – 2015-11-11
Reproduction forbidden without written authorization from Telit Communications S.p.A. - All Rights Reserved. Page 24 of 88
41
N/C
-
Not connected internally on
M.2
-
42
I2C_SDA
IO
I2C Data – GNSS Support
1.8 V
43
N/C
-
Not connected internally on
M.2
44
I2C_IRQ
I
GNSS Interrupt Request –
GNSS Support
1.8 V
45
GND
P
Ground
-
46
SYSCLK
O
26 MHz reference Clock
output for external GNSS
module
1.8 V
47
N/C
-
Not connected internally on
M.2
-
48
TX_BLANKING
O
GNSS Blanking Signal used to
indicate 2G Tx burst and LTE
band 13 Tx burst.
1.8 V
49
N/C
-
Not connected internally on
M.2
-
50
N/C
-
Not connected internally on
M.2
-
51
GND
P
Ground
-
52
N/C
-
Not connected internally on
M.2
-
53
N/C
-
Not connected internally on
M.2
-
54
N/C
-
Not connected internally on
M.2
-
55
N/C
-
Not connected internally on
M.2
-
56
N/C
-
Not connected internally on
M.2
-
57
GND
P
Ground
-
58
N/C
-
Not connected internally on
M.2
-
59
ANTCTL0
O
RF Antenna Tuning Control
Signal 0
1.8 V
60
COEX3
O
Wireless Coexistence between
WWAN and WiFi/BT
modules. IDC_LteDtxEnv
1.8 V
61
ANTCTL1
O
RF Antenna Tuning Control
Signal 1
1.8 V
62
COEX2
I
Wireless Coexistence between
WWAN and WiFi/BT
modules. IDC_CwsPriority
1.8 V
63
ANTCTL2
O
RF Antenna Tuning Control
Signal 2
1.8 V
64
COEX1
O
Wireless Coexistence between
WWAN and WiFi/BT
modules. IDC_LteFrameSync
1.8 V
65
ANTCTL3
O
RF Antenna Tuning Control
Signal 3
1.8 V
66
SIM DETECT
I
SIM Card Detection (I) (low
active).
• Pull-up resistor on WWAN
M.2 module
1.8 V
67
RESET#
I
Single control to reset WWAN
1.8 V
68
N/C
-
Not connected internally on
M.2
-
