Safety warning symbol for an electrical danger to personnel. The no respect of this
warning can cause serious injuries.
The repair methods described by TELMA SA, in this document, are based on the technical
specifications in effect at the date of this writing. They are subject to modifications in case of
changes done by TELMA SA to manufacture the various component units and accessories brand
(?) products.
The company TELMA SA reserves the right to modify the characteristics of its products at any time
in order to incorporate the latest technological developments. The information contained in this
document are subject to change without notice.
- We would like to draw your attention to the contents of this maintenance manual.
Indeed, following the respect of important points during installation, use and maintenance
of your retarder will ensure trouble-free operation for many years.
- When using lifting equipment, do not walk or stand under suspended loads.
- For information, a complete retarder weights around 330 kg (728 lb), a rotor with coupling
flange weights about 63kg (139 lb), and a hub weights 5.5 kg (12 lb).
- Put the retarder on a solid table, with the handling safety tool.
- Pay attention to the heavy parts of the retarder which can cause serious personal injury.
3. REQUIRED TOOLS
- Protective glasses and gloves
- Handling safety tools for retarder
- Flat screwdriver
- Torx® TX40 socket
- Click-type wrench
- 10 mm long socket and 19mm socket
- Tab washer driver (See Annexe 1)
- Hammer
- Feeler gauge
- Dial gauge with magnetic base
- Ink marker
- Torque wrench (torque values: 45Nm, 60Nm and 68Nm)
- Abrasive cloth (120 grade)
