BreezeCOMPACT System Manual
Chapter 3 - Operation and AdministrationBS Menu
Chapter 3 - Operation and Administration BS Menu
64
A change in Paging Group ID will take effect after next reset.
3.7.2.2 Air Frame Structure
The Air Frame Structure menu includes the following options:
Zones
General
DL Diversity Mode
3.7.2.2.1 Zones
The Air Frame Structure - Zones menu includes the following options:
Uplink Data Zone
Downlink Data Zone
First Zone
Uplink Feedback Zone
Frame Structure Mode
3.7.2.2.1.1 Uplink Data Zone
The Uplink Data Zone menu enables viewing/updating the values configured for the following
parameters:
Uplink Basic Rate
UL Permutation Base
3.7.2.2.1.1.1 Uplink Basic Rate
The uplink basic rate:
ctcQpskOneOverTwoTimesSix (QPSK 1/2 Repetition 6)
ctcQpskOneOverTwoTimesFour (QPSK 1/2 Repetition 4)
ctcQpskOneOverTwoTimesTwo (QPSK 1/2 Repetition 2)
ctcQpskOneOverTwo (QPSK 1/2)
ctcQpskThreeOverFour (QPSK 3/4)
ctcQamSixteenOneOverTwo 16-QAM 1/2
ctcQamSixteenThreeOverFour (16-QAM 3/4)
ctcQamSixtyFourOneOverTwo (64-QAM 1/2)
ctcQamSixtyFourTwoOverThree (64-QAM 2/3)
ctcQamSixtyFourThreeOverFour (64-QAM 3/4)
ctcQamSixtyFourFiveOverSix 64-QAM 5/6
