Chapter 3: Installation
Caution:
The TLS-4A generates up to 95 VAC ringing voltage. Be sure the
TLS-4A power switch is off before handling cord ends.
Step 1: Connect power cord
·
Connect the AC power cord to the TLS-4A and to the wall receptacle.
Step 2: Connect telephones
·
Plug up to four telephones or other telecommunications devices into the
line jacks on the TLS-4A front panel.
Step 3: Turn on power
·
Turn the TLS-4A power switch on.
Step 4: Chassis ground (optional)
· If a chassis ground is required, plug a 0.080-inch diameter pin probe into
the chassis ground reference Jack on the back panel. The location is shown
in Figure 1.
Step 5: Audio port (optional)
· To generate or play a recorded tape message, refer to Generating a Tape,
later in this chapter.
Demonstrating Equipment
Caution:
The TLS-4A generates 95 V ringing voltage. Be sure the TLS-4A power
switch is off before handling any cord ends.
To demonstrate equipment, do the following:
·
With two devices connected to the TLS-4A, place a call from one device to
the other by dialing the number of the other device. The default numbers
for Lines 1 through 4 are 101 through 104, respectively.
Note:
If you wish, you can change the phone number for any line to any digit
string from 1 through 16 digits by reprogramming the line as described in
Chapter 6.)
·
When the other line rings, answer the call. A connection should be
established and equipment features can be demonstrated.
·
When the call is completed, hang up both devices.
Reference Manual Chapter 3: Installation
40-400-00033, Rev. C
Page 7
