Set up your device
How to insert Micro SIM card and
connect the battery
1. Gently remove MTB100 cover using plastic pry tool from both
sides.
2. Insert Micro-SIM card as shown with PIN request disabled or
read Security info how to enter it later in Configurator. Make
sure that Micro-SIM card cut-off corner is pointing forward to
slot.
3. Connect battery as shown to device. Position the battery in
place where it does not obstruct other components.
4. Attach device cover back. Device is ready to be connected.
Figure 4 Cover removal
Figure 5 Micro SIM card insert Figure 6 Battery connection
Figure 7 Attaching cover back
