Teltonika MTB100 - PC Connection (Windows); How to Install USB Drivers (Windows); Configuration (Windows)

7
MTB100 | Wiki
PC Connection (Windows)
1. Power-up MTB100 with DC voltage 6-30 V power supply using
power cable. LED’s should start blinking, see “LED indications”.
2. Connect device to computer using Micro-USB cable or
Bluetooth connection:
• Using Micro-USB cable
▬ You will need to install USB drivers, see "How to install
USB drivers (Windows)"
• Using Bluetooth
▬ MTB100 Bluetooth is enabled by default. Turn on
Bluetooth on your PC, then select Add Bluetooth or
other device > Bluetooth. Choose your device named –
“MTB100_last_7_imei_digits”, without LE in the end.
Enter default password 5555, press Connect and then
select Done.
3. You are now ready to use the device on your computer.
How to install USB drivers
(Windows)
1. Please download COM port drivers from here.
2. Extract and run TeltonikaCOMDriver.exe.
3. Click Next in driver installation window.
4. In the following window click Install button.
5. Setup will continue installing the driver and eventually the
confirmation window will appear. Click Finish to complete the
setup.
Configuration (Windows)
At first MTB100 device will have default factory settings set. These
settings should be changed according to the user's needs. Main
configuration can be performed via Teltonika Configurator
software. Get the latest MTB100 Configurator version from here.
Configurator operates on Microsoft Windows OS and uses
prerequisite MS .NET Framework. Make sure you have the correct
version installed.
Table 2 MS .NET requirements
MS .NET REQUIREMENTS
Windows Vista
Windows 7
Windows 8.1
Windows 10
MS .NET Framework
4.6.2
32 and 64 bit www.microsoft.com
Downloaded Configurator will be in compressed archive. Extract it
and launch Configurator.exe. After launch software language can
be changed by clicking in the right bottom corner (Figure 8
Language selection).
