Setting The Clock
The TZT-701 thermostat is fitted with a real time clock. It is essential that the clock time and day are set accurately if you want
your programmed events to start on time.
To set the clock, tap the clock button. The LCD will show the Hours Digit flashing. Use the up (p) or down (q) button to adjust
the hours to the correct time (note the AM / PM symbol) Tap the clock button again and now the minute’s digits will flash.
Adjust this value using the up (p) or down (q) button to show the correct minute. Tap the Clock button again and now the week
day flashes, again use the up (p) or down (q) button to set this value to the correct day of the week. Tap the clock button again
to exit the clock set function. Your clock is now set.
Programming Your 4 Daily Events
The TZT-701 is an individual 7-day programmable thermostat. For each day of the week you are able to have 4 time schedules or
programmed events. For clarity these events are conveniently named “Wake”, “Leave”, “Return” & “Sleep”.
The “Wake” event may be used to set the temperatures of your home that you would like to wake up to.
The “Leave” event is typically used to set the temperatures you wish your home to maintain whilst you are away at work.
The “Return” event is often used to set the temperature you wish to be greeted with upon returning home at the end of the day.
The “Sleep” event can be used to set a comfortable and energy efficient temperature while you sleep.
You are permitted to have every event occur at a different time of the day and set a different heating and cooling set temperature
for each of the 4 events. You are able to set a heating set point temperature between Heating OFF and 38 degrees Celsius. You
are able to set a cooling temperature between zero degrees Celsius and Cooling OFF.
Programming your TZT-701 thermostat or setting these daily events is no more complicated than setting the clock as described
previously. The same buttons are used in the same sequence, using the Clock button to advance to the next step, and the up (p)
or down (q) buttons to make changes. The LCD shows only relevant information for the event being adjusted thus reducing
possible errors that may be caused by having confusing information displayed on the LCD.
To enter the program mode, press and hold the Clock button for 5 seconds. The display will change to show the Day “Monday”
flashing. Using the up (p) or down (q) buttons adjust the day to the day you wish to start programming an event or to the day
you wish to edit an existing event.
Tap the clock button to advance to the next step, The LCD will show the word “Wake” with the hour’s digit flashes. Using the
up (p) or down (q) buttons adjust the hours to the time you wish the “Wake” event to commence for the currently selected day.
Tap the Clock button again, now the minute’s digits flashes. Using the up (p) or down (q) buttons set the minute to the time
you wish the “Wake” event to commence.
Tap the Clock button again. If the TZT-701 thermostat has been set by the installer to control the optional climate zoning AND if
the option to program the zones has been set by the installer, you will now have the ability to set which zones you require to be
ON during the wake event. Using the up (p) or down (q) buttons set the zones you wish to be ON for the “Wake” event.
If the installer has set the Zone option “OFF”, this step is skipped by the TZT-701 during the programming sequence.
Tap the Clock button again, now the word “Heat” (if heating mode is enabled by the installer) and a temperature value is shown
in the LCD, using the up (p) or down (q) buttons set the desired Heating temperature for the “Wake” event. Tap the Clock
button again, now the word “Cool” (if cooling mode is enabled by the installer) and a temperature value is shown in the LCD,
using the up (p) or down (q) buttons set the desired Cooling temperature for the Wake event.
NOTE: there must be a minimum of 1 deg C difference between heating and cooling set points. The heating temperature must be
at least 1 deg C lower than the cooling set temperature. If you set the heating or cooling set point closer than this minimum
value, the TZT-701 thermostat will automatically “push” the other set point away to maintain this minimum value.
Tap the Clock button again and the Day previously selected will be shown along with the word “Leave”. The Hour digit will
flash indicating that this value can now be adjusted with the up (p) or down (q) buttons. Set the hour to the time you wish the
“Leave” event to commence.
Continue to tap the Clock button to advance you through the “Leave” “Minute”, then “Leave” Zone (if enabled) “Leave” Heating
(if enabled) and “Leave” cooling (if enabled) temperatures. Again by continuing to tap the Clock button you will advance to
through the “Return” program and then “Sleep” programs for the day you have chosen to program.
Taping the Clock button again the LCD will now show the word “COPY”.
You now have TWO options
Option 1 - Continue programming as above.
Simply continue to tap the Clock Button as you have been to advance to the next day, “Tuesday” in this example “Wake”,
“Leave”, “Return”, “Sleep” then Wednesday, Thursday etc, following the same simple steps previously explained, …. OR ….
