TempMaster OmniElite - Nomenclature

TEMPMASTER
2
FORM TPM3-EG1 (518)
Nomenclature
ASHRAE
90.1
COMPLIANT
Approvals
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17
BASE PRODUCT TYPE NOMINAL CAPACITY APPLICATION REFRIGERANT VOLTAGE DUCT LOCATIONS DESIGN SPECIAL GAS HEAT CAPACITY
X : Standard Product, IPU
S : Special Product, IPU
E : R-410A
6 : 460 / 3 / 60
8 : 575 / 3 / 60
V : VAV or SZVAV
B : Bottom Return
R : Rear Return
S : Side Return
C : Cooling Only
N : Natural Gas Heat
G : Natural Gas Heat Stainless Steel Heat Exchanger
M : Modulating Gas Heat
E : Electric Heat
S : Steam Heat
H : Hot Water Heat
L : Scroll
M : Packaged Rooftop
A : Air-Cooled
T : TempMaster
: 120-ton
: 130-ton
: 150-ton
0
0
0
2
3
5
1
1
1
4
5
B : Bottom Supply
L : Left Supply
R : Right Supply
G
N : No Gas Heat
L : Low (375 mbh)
M : Medium (750 mbh)
H : High (1125 mbh)
BASE MODEL NUMBER TMAL120–150
