TEMPMASTER
FORM TPM3-EG1 (518)
Cooling Performance Data
TABLE 7 - COOLING PERFORMANCE DATA* – 120 TON MODEL
AIR ENTERING
EVAPORATOR
COIL
OUTDOOR AMBIENT TEMPERATURE 75.0°F
ENTERING DRY BULB TEMPERATURE
CFM
WET
BULB (°F)
92.0°F 86.0°F 80.0°F 74.0°F 68.0°F
TMBH SMBH TMBH SMBH TMBH SMBH TMBH SMBH TMBH SMBH
32000
75 1778.4 1080.0 1777.1 907.1 1773.2 732.3
71 1660.9 1202.8 1660.9 1031.4 1659.3 855.9 1659.3 674.7
67 1552.6 1325.4 1552.6 1155.3 1550.9 974.7 1550.9 797.9 1550.9 621.1
62 1491.5 1443.6 1425.1 1309.3 1423.2 1126.8 1421.7 951.0 1420.2 775.1
34500
75 1802.4 1124.4 1800.2 935.7 1797.3 745.6
71 1684.4 1258.4 1684.0 1071.4 1682.8 879.6 1682.8 683.4
67 1587.6 1376.3 1586.2 1210.8 1584.9 1013.5 1584.9 822.0 1584.9 630.6
62 1530.6 1488.1 1462.4 1355.8 1461.0 1183.4 1459.9 992.1 1458.7 800.8
37000
75 1826.5 1168.9 1823.4 964.3 1821.4 758.9
71 1707.9 1314.0 1707.0 1111.4 1706.2 903.3 1706.2 692.2
67 1622.5 1427.2 1619.8 1266.2 1618.9 1052.2 1618.9 846.1 1618.9 640.0
62 1569.7 1532.6 1499.7 1402.3 1498.8 1240.0 1498.0 1033.3 1497.3 826.5
39500
75 1850.5 1213.4 1846.5 992.8 1845.5 772.2
71 1731.4 1369.5 1730.1 1151.3 1729.7 927.0 1729.7 700.9
67 1657.5 1478.0 1653.4 1321.7 1653.0 1091.0 1653.0 870.2 1653.0 649.5
62 1608.8 1577.1 1537.0 1448.8 1536.5 1296.6 1536.2 1074.4 1535.8 852.2
42000
75 1874.6 1257.9 1869.6 1021.4 1869.6 785.5
71 1754.8 1425.1 1753.1 1191.3 1753.1 950.7 1753.1 709.6
67 1692.4 1528.9 1687.0 1377.1 1687.0 1129.7 1687.0 894.3 1687.0 658.9
62 1648.0 1621.6 1574.3 1495.3 1574.3 1353.2 1574.3 1115.6 1574.3 877.9
44500
75 1889.9 1301.0 1886.2 1049.3 1885.6 797.6
71 1770.3 1479.3 1768.2 1229.8 1767.5 972.4 1767.5 717.1
67 1702.0 1551.9 1698.0 1424.0 1698.0 1159.6 1698.0 910.3 1698.0 660.9
62 1679.4 1656.2 1597.8 1528.5 1572.1 1374.8 1571.1 1130.2 1570.1 885.7
47000
75 1905.3 1344.1 1902.8 1077.1 1901.6 809.6
71 1785.8 1533.5 1783.3 1268.3 1781.9 994.0 1781.9 724.5
67 1711.6 1575.0 1708.9 1470.9 1708.9 1189.5 1708.9 926.2 1708.9 662.9
62 1710.8 1690.8 1621.4 1561.6 1569.9 1396.3 1567.9 1144.9 1565.8 893.5
49500
75 1920.6 1387.2 1919.3 1105.0 1917.5 821.7
71 1801.2 1587.6 1798.4 1306.7 1796.3 1015.7 1796.3 731.9
67 1721.2 1598.0 1719.9 1517.7 1719.9 1219.4 1719.9 942.2 1719.9 664.9
62 1742.1 1725.4 1644.9 1594.8 1567.7 1417.9 1564.6 1159.5 1561.6 901.2
52000
75 1935.9 1430.3 1935.9 1132.8 1933.5 833.7
71 1816.7 1641.8 1813.5 1345.2 1810.7 1037.3 1810.7 739.4
67 1730.8 1621.0 1730.8 1564.6 1730.8 1249.3 1730.8 958.1 1730.8 666.9
62 1773.5 1760.0 1668.4 1627.9 1565.5 1439.4 1561.4 1174.2 1557.3 909.0
* Rated performance is at sea level. Cooling capacities are gross cooling capacity.
