TEMPMASTER
24
FORM TPM3-EG1 (518)
TABLE 7 – COOLING PERFORMANCE DATA* – 120 TON MODEL (CONT’D)
AIR ENTERING
EVAPORATOR
COIL
OUTDOOR AMBIENT TEMPERATURE 85.0°F
ENTERING DRY BULB TEMPERATURE
CFM
WET
BULB (°F)
92.0°F 86.0°F 80.0°F 74.0°F 68.0°F
TMBH SMBH TMBH SMBH TMBH SMBH TMBH SMBH TMBH SMBH
32000
75 1708.2 1052.4 1706.8 879.6 1702.1 704.6
71 1596.2 1175.4 1595.9 1004.0 1594.2 828.6 1594.2 647.4
67 1489.4 1296.6 1488.0 1126.1 1487.1 945.9 1487.1 769.1 1487.1 592.4
62 1442.9 1407.3 1378.7 1286.1 1377.8 1104.2 1377.0 928.8 1376.3 753.5
34500
75 1731.2 1097.0 1729.6 908.4 1726.0 718.3
71 1618.4 1230.9 1617.9 1044.0 1616.7 852.4 1616.7 656.2
67 1525.2 1346.8 1510.0 1177.0 1509.4 980.0 1509.4 788.7 1509.4 597.4
62 1462.6 1430.7 1414.5 1329.2 1394.3 1151.2 1393.7 960.4 1393.1 769.5
37000
75 1754.2 1141.6 1752.3 937.3 1750.0 732.1
71 1640.6 1286.5 1640.0 1084.1 1639.2 876.2 1639.2 665.1
67 1561.1 1397.0 1532.1 1227.9 1531.7 1014.2 1531.7 808.3 1531.7 602.3
62 1482.4 1454.1 1450.3 1372.3 1410.8 1198.2 1410.4 991.9 1410.0 785.6
39500
75 1777.1 1186.1 1775.1 966.1 1773.9 745.8
71 1662.8 1342.1 1662.1 1124.1 1661.7 900.1 1661.7 674.0
67 1597.0 1447.2 1554.2 1278.8 1554.0 1048.4 1554.0 827.8 1554.0 607.3
62 1502.1 1477.4 1486.1 1415.5 1427.3 1245.3 1427.1 1023.5 1426.9 801.7
42000
75 1800.1 1230.7 1797.8 995.0 1797.8 759.5
71 1685.1 1397.6 1684.2 1164.1 1684.2 923.9 1684.2 682.8
67 1632.9 1497.4 1576.3 1329.7 1576.3 1082.6 1576.3 847.4 1576.3 612.2
62 1521.9 1500.8 1521.9 1458.6 1443.8 1292.3 1443.8 1055.1 1443.8 817.8
44500
75 1813.5 1273.6 1811.5 1022.3 1811.0 771.0
71 1702.5 1439.3 1697.2 1202.2 1696.8 945.2 1696.8 690.0
67 1647.6 1528.4 1593.1 1379.7 1592.8 1115.4 1592.8 866.2 1592.8 617.1
62 1566.3 1548.8 1532.5 1480.0 1472.1 1341.6 1466.1 1088.5 1460.1 835.3
47000
75 1826.8 1316.4 1825.1 1049.6 1824.3 782.5
71 1720.0 1480.9 1710.2 1240.3 1709.4 966.6 1709.4 697.1
67 1662.3 1559.5 1609.9 1429.7 1609.3 1148.2 1609.3 885.0 1609.3 621.9
62 1610.7 1596.8 1543.1 1501.4 1500.5 1391.0 1488.4 1121.9 1476.3 852.8
49500
75 1840.2 1359.2 1838.8 1076.9 1837.5 794.0
71 1737.4 1522.5 1723.2 1278.4 1722.0 987.9 1722.0 704.3
67 1677.0 1590.6 1626.7 1479.7 1625.8 1180.9 1625.8 903.9 1625.8 626.8
62 1655.1 1644.7 1553.7 1522.7 1528.8 1440.3 1510.7 1155.3 1492.6 870.3
52000
75 1853.5 1402.1 1852.4 1104.3 1850.7 805.5
71 1754.8 1564.1 1736.2 1316.5 1734.7 1009.2 1734.7 711.4
67 1691.7 1621.6 1643.5 1529.7 1642.4 1213.7 1642.4 922.7 1642.4 631.7
62 1699.5 1692.7 1564.4 1544.1 1557.1 1489.6 1533.0 1188.7 1508.8 887.8
* Rated performance is at sea level. Cooling capacities are gross cooling capacity.
