Component Static Pressure Drops
TABLE 15 - COMPONENT STATIC PRESSURE DROPS (INCHES OF WATER COLUMN)
SIZE
AIRFLOW CFM
STD AIR
DISCHARGE
AIR OPENING
120 & 130 TON DAMPERS 150 TON DAMPERS
POWERED EXHAUST
AIR DAMPER
SIDE
BOTTOM
STANDARD
OUTSIDE
AIR DAMPER
& HOODS
WITH 1-INCH
CLEANABLE
FILTERS
LOW LEAK
OUTSIDE
AIR DAMPER
& HOODS
WITH 1-INCH
CLEANABLE
FILTERS
BOTTOM
& REAR
RETURN
AIR
DAMPERS
STANDARD
OUTSIDE
AIR DAMPER
& HOODS
WITH 1-INCH
CLEANABLE
FILTERS
LOW LEAK
OUTSIDE
AIR DAMPER
& HOODS
WITH 1-INCH
CLEANABLE
FILTERS
BOTTOM
& REAR
RETURN
AIR
DAMPERS
120–150T
24,000 0.11 0.08 0.18 0.17 0.13 0.13 0.13 0.08 0.018
26,000 0.13 0.09 0.21 0.20 0.15 0.16 0.15 0.10 0.021
28,000 0.15 0.11 0.24 0.23 0.17 0.18 0.18 0.12 0.025
30,000 0.17 0.12 0.28 0.26 0.20 0.21 0.21 0.13 0.029
32,000 0.19 0.14 0.31 0.30 0.22 0.24 0.23 0.15 0.032
34,000 0.22 0.16 0.36 0.34 0.25 0.27 0.27 0.17 0.037
36,000 0.25 0.18 0.40 0.38 0.28 0.31 0.30 0.19 0.041
38,000 0.27 0.20 0.45 0.43 0.31 0.34 0.33 0.21 0.046
40,000 0.30 0.22 0.50 0.47 0.35 0.38 0.37 0.24 0.051
42,000 0.33 0.24 0.55 0.52 0.38 0.42 0.41 0.26 0.056
44,000 0.37 0.26 0.60 0.58 0.42 0.46 0.45 0.28 0.061
46,000 0.40 0.29 0.66 0.63 0.46 0.51 0.49 0.31 0.067
48,000 0.44 0.31 0.72 0.69 0.50 0.55 0.54 0.34 0.073
50,000 0.47 0.34 0.78 0.75 0.54 0.60 0.59 0.37 0.079
52,000 0.51 0.37 0.85 0.81 0.59 0.65 0.63 0.40 0.086
TABLE 14 - TMAL120–150: DUAL DIRECT DRIVE PLENUM (DDP) 330-120 FAN
TOTAL STATIC PRESSURE (INCHES OF WATER COLUMN)
CFM
STD AIR
2.0 3.0 4.0 5.0 6.0
RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
24,000 849 11.0 979 16.5 1107 22.6 1228 29.3 1341 36.3
26,000 878 12.1 998 17.8 1117 24.0 1234 30.9 1345 38.2
28,000 910 13.2 1022 19.2 1133 25.6 1243 32.6 1350 40.1
30,000 944 14.5 1049 20.7 1153 27.3 1256 34.5 1358 42.1
32,000 980 15.9 1078 22.3 1176 29.2 1273 36.5 1370 44.3
34,000 1017 17.4 1110 24.1 1202 31.2 1294 38.7 1385 46.7
36,000 1055 19.0 1144 26.0 1231 33.3 1317 41.1 1404 49.2
38,000 1094 20.7 1179 28.0 1261 35.6 1344 43.6 1426 51.9
40,000 1133 22.5 1216 30.1 1294 38.0 1372 46.2 1450 54.8
42,000 1174 24.4 1253 32.4 1328 40.5 1403 49.0 1477 57.8
44,000 1214 26.5 1291 34.7 1364 43.3 1435 51.9 1506 61.0
46,000 1256 28.7 1329 37.3 1400 46.1 1468 55.1 1536 64.4
48,000 1297 31.1 1368 39.9 1437 49.1 1503 58.4 1568 67.9
50,000 1339 33.6 1408 42.7 1475 52.2 1539 61.9 1602 71.6
52,000 1382 36.2 1449 45.7 1513 55.5 1576 65.5 NA NA
NOTE: Data is for two fans.
NA = Not Available
