TempMaster OmniElite - Electric Heat Pressure Drops; Gas Heat Pressure Drops

TEMPMASTER
42
FORM TPM3-EG1 (518)
Electric Heat Pressure Drops
TABLE 17 - ELECTRIC HEAT AIR PRESSURE DROPS (INCHES OF WATER COLUMN)
SIZE
AIRFLOW
CFM STD AIR
80 KW 100 KW 108 KW 150 KW 200 KW 250 KW
120–150T
24,000 0.04 0.08 0.09 0.11 0.14 0.18
26,000 0.05 0.09 0.10 0.12 0.16 0.21
28,000 0.06 0.10 0.12 0.14 0.19 0.24
30,000 0.07 0.12 0.14 0.17 0.22 0.28
32,000 0.08 0.13 0.15 0.19 0.25 0.31
34,000 0.09 0.15 0.17 0.21 0.28 0.35
36,000 0.10 0.17 0.20 0.24 0.31 0.40
38,000 0.11 0.19 0.22 0.26 0.35 0.44
40,000 0.12 0.21 0.24 0.29 0.39 0.49
42,000 0.13 0.23 0.27 0.32 0.43 0.54
44,000 0.15 0.25 0.29 0.36 0.47 0.59
46,000 0.16 0.28 0.32 0.39 0.51 0.65
48,000 0.17 0.30 0.35 0.42 0.56 0.71
50,000 0.19 0.33 0.38 0.46 0.60 0.77
52,000 0.20 0.35 0.41 0.50 0.65 0.83
TABLE 16 - ELECTRIC HEATER SIZE AVAILABILITY BY UNIT SIZE
MODEL
80KW
100KW 108KW 150KW 200KW 250KW
TMAL120–150 X X X X X X
Gas Heat Pressure Drops
TABLE 18 - GAS HEAT AIR PRESSURE DROPS (INCHES OF WATER COLUMN)
SIZE
AIRFLOW CFM
STD AIR
1125 MBH
120–150T
24,000 0.20
26,000 0.23
28,000 0.27
30,000 0.31
32,000 0.35
34,000 0.40
36,000 0.45
38,000 0.50
40,000 0.55
42,000 0.61
44,000 0.67
46,000 0.73
48,000 0.80
50,000 0.87
52,000 0.94
