39
TEMPMASTER
FORM TPM3-EG1 (518)
Supply Fan Data
TABLE 12 - TMAL120–150: 40-INCH AIRFOIL SUPPLY FAN
TOTAL STATIC PRESSURE (INCHES OF WATER COLUMN)
CFM
STD AIR
2.0 3.0 4.0 5.0 6.0
RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
24,000 658 12.6 753 18.5 846 25.2 940 33.3 1027 42.1
26,000 678 14.0 772 20.1 857 26.8 943 34.6 1030 43.6
28,000 700 15.4 792 21.9 872 28.8 952 36.3 1032 45.1
30,000 724 17.0 812 23.8 891 31.0 965 38.5 1039 47.0
32,000 747 18.7 832 25.8 911 33.3 982 41.1 1051 49.4
34,000 771 20.5 854 28.0 931 35.8 1000 44.0 1066 52.4
36,000 796 22.6 878 30.3 951 38.4 1020 46.9 1084 55.7
38,000 822 24.8 901 32.8 973 41.2 1041 50.0 1103 59.1
40,000 848 27.2 925 35.4 995 44.2 1061 53.3 1123 62.7
42,000 875 29.8 949 38.3 1018 47.3 1082 56.7 1144 66.5
44,000 901 32.5 974 41.3 1042 50.7 1104 60.4 1164 70.4
46,000 928 35.4 1000 44.7 1065 54.2 1127 64.2 1185 74.5
48,000 955 38.6 1026 48.2 1089 57.9 1151 68.3 1207 78.9
50,000 983 41.9 1052 51.9 1114 62.0 1174 72.5 1230 83.5
52,000 1011 45.5 1079 55.9 1140 66.2 1198 77.0 1254 88.3
TABLE 13 - TMAL120–150: DUAL DIRECT DRIVE PLENUM (DDP) 330-100 FAN
TOTAL STATIC PRESSURE (INCHES OF WATER COLUMN)
CFM
STD AIR
2.0 3.0 4.0 5.0 6.0
RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
24,000 904 11.2 1017 16.3 1130 21.9 1241 27.9 1349 34.4
26,000 943 12.4 1047 17.7 1151 23.5 1255 29.7 1358 36.4
28,000 984 13.7 1082 19.3 1178 25.3 1275 31.7 1371 38.5
30,000 1027 15.2 1119 21.0 1209 27.3 1299 33.9 1389 40.9
32,000 1072 16.7 1158 22.9 1243 29.4 1328 36.2 1412 43.4
34,000 1117 18.4 1200 24.9 1280 31.6 1359 38.7 1439 46.1
36,000 1163 20.3 1242 27.0 1319 34.1 1394 41.3 1469 49.0
38,000 1209 22.2 1286 29.3 1359 36.6 1431 44.2 1502 52.0
40,000 1257 24.3 1331 31.7 1401 39.4 1469 47.2 1537 55.3
42,000 1304 26.6 1376 34.3 1444 42.3 1509 50.4 1574 58.7
44,000 1352 29.0 1422 37.1 1487 45.3 1551 53.7 1613 62.4
46,000 1401 31.6 1469 40.0 1532 48.6 1593 57.3 NA NA
48,000 1450 34.3 1516 43.1 1577 52.0 NA NA NA NA
50,000 1500 37.3 1563 46.3 1623 55.6 NA NA NA NA
52,000 1549 40.4 1611 49.8 NA NA NA NA NA NA
NOTE: Data is for two fans.
NA = Not Available
