TABLE 3 - PHYSICAL DATA – MODELS 120–150
Physical Data
MODEL SIZE 120 130 150
COMPRESSOR DATA
Quantity/Size (nominal HP) 4x15/2x25 2x15/2x20/2x25 2X15/2X20/2X32
Type Scroll Scroll Scroll
Capacity Steps 14 steps providing capacity control between 12 and 100%
DOUBLE WIDTH, DOUBLE INLET (DWDI) AIRFOIL SUPPLY FAN AND DRIVE
Quantity 1 1 1
Size 40 40 40
Motor Size Range (min. to max. HP) 10–100 10–100 10–100
Airow Range (min. to max. CFM) 30000–52000 32000–52000 36000–52000
Static Pressure Range (min. to max. ESP) 0–6 inches 0–6 inches 0–6 inches
DIRECT DRIVE PLENUM (DDP) SUPPLY FAN AND DRIVE
Quantity 2 2 2
Size 330-100/120 330-100/120 330-100/120
Motor Size Range (min. to max. HP) 10–60 10–60 10–60
Airow Range (min. to max. CFM) 20000–45000/52000 20000–45000/52000 20000–45000/52000
Static Pressure Range (min. to max. ESP) 1–8 inches 1–8 inches 1–8 inches
EXHAUST FAN
Quantity 1 1 1
Type DWDI Forward-Curved
Size 32–32 32–32 32–32
Motor Size Range (min. to max. HP) 7.5–60 7.5–60 7.5–60
Airow Range (min. to max. CFM) 0–50000 0–50000 0–50000
Static Pressure Range (min. to max. ESP) 0–2 inches 0–2 inches 0–2 inches
RETURN FAN
Quantity Fans/Motors 1 1 1
Type SWSI Plenum SWSI Plenum SWSI Plenum
Size 445 445 445
Motor Size Range (min. to max. HP) 10–50 10–50 10–50
Airow Range (min. to max. CFM) 0–50000 0–50000 0–50000
Static Pressure Range (min. to max. iwg) 0–3 0–3 0–3
EVAPORATOR COIL
Size (sq. ft.) 81.7 81.7 81.7
Number Of Rows/Fins Per Inch 5 / 10 5 / 10 5 / 10
Tube Diameter (inches) 1/2 1/2 1/2
CONDENSER COIL
Size (sq. ft.) 262 262 262
Number Of Rows/Fins Per Inch 1/21 1/21 1/21
CONDENSER FANS
Quantity 9 9 9
Type Prop Prop Prop
Diameter (inches) 36 36 36
Power (HP) 2 2 2
FILTERS - 2-INCH CLEANABLE (PRE-FILTER POSITION)
Quantity 36/12 36/12 36/12
Size (length x width in inches) 16x20/20x20 16x20/20x20 16x20/20x20
Total Filter Face Area (sq. ft.) 113.3 113.3 113.3
FILTERS - 2-INCH PLEATED, 30% EFFICIENT (PRE-FILTER POSITION) (MERV 8)
Quantity 36/12 36/12 36/12
Size (length x width in inches) 16x20/20x20 16x20/20x20 16x20/20x20
Total Filter Face Area (sq. ft.) 113.3 113.3 113.3
