Weight Data
TABLE 5 - APPROXIMATE BASE OPERATING
WEIGHTS (LBS)
MODEL SIZE 120 130 150
SINGLE PIECE UNIT 18,238 18,847 18,938
TWO PIECE UNIT
Air Handler Section 12,131 12,325 12,332
Condenser Section 6,096 6,510 6,597
NOTES:
• Weights above are total weight excluding the curb
• Standard cabinet
• Cooling only
• 60 HP supply fan with variable frequency drive (VFD)
• Comparative enthalpy economizer
• Barometric relief exhaust
• Bottom supply and return
• 2-inch pleated lters
• Condenser section wire guards
• Weights represent approximate operating weights and have a
+/- 10% accuracy. To calculate weight for a specic congura-
tion, contact a TempMaster sales representative.
TABLE 6 - COMPONENT WEIGHTS (LBS)
MODEL SIZE 120 130 150
CABINET, AIR HANDLING SECTION
Sheet Metal (Note 1) 6,310
Control Panel (Note 2) 705
REFRIGERANT
Refrigerant Charge (R-410A) 210 230 230
COMPRESSORS 826 1,661 1,738
CONDENSER ASSEMBLY
Sheet Metal 2,477
Coils 864
Condenser Fans 90
Condenser Motors 450
Condenser Grills 90
Wire Guards 266
Louvered Panel Guards 432
DWDI AIRFOIL SUPPLY FAN SKID WITHOUT MOTOR (NOTE 3) 1,696
SUPPLY FAN MOTOR DRIVE 80
DUAL DIRECT DRIVE PLENUM (DDP) FAN SKIDS WITHOUT MOTOR
Frame 215T DDP 330-100/120 565/579
Frame 254T DDP 330-100/120
584/597
Frame 256T DDP 330-100/120
Frame 284T DDP 330-100/120
608/621
Frame 286T DDP 330-100/120
Frame 324T DDP 330-100/120
692/705
Frame 326T DDP 330-100/120
Frame 364T DDP 330-100/120 709/722
MOTOR (SUPPLY/EXHAUST/RETURN)
7.5 HP 151
10 HP 165
15 HP 255
20 HP 286
25 HP 379
30 HP 437
40 HP 578
50 HP 700
60 HP 885
75 HP 930
100 HP 1,225
VARIABLE FREQUENCY DRIVE (VFD) (SUPPLY/EXHAUST/RETURN)
5–10 HP 16
15–25 HP 27
30–40 HP 51
50–75 HP 77
100 HP 110
