TempMaster OmniElite - Page 22

TEMPMASTER
22
FORM TPM3-EG1 (518)
MODEL SIZE 120 130 150
EVAPORATOR COILS 921 1,106 1,106
FILTERS
2-inch Cleanable Aluminum 74
2-inch Pleated 40
2-inch Carbon 94
Return Filter - 2-inch Throwaway (Note 4) 30
Return Filter - 12-inch 60–65% (Note 4) 393
Return Filter - 12-inch 90–95% (Note 4) 388
Final Filters 327
ECONOMIZER
Outside Air Dampers 255
Outside Air Hoods 291
Outside Air Filters 103
EXHAUST FAN SKID WITHOUT MOTOR 1,147
RETURN FAN SKID WITHOUT MOTOR 1,574
EXHAUST
No Exhaust - End Panels 332
Exhaust Fan (Damper and Hood) 516
Return Fan (Damper and Hood) 539
HEATING OPTIONS
Electric Heat - 80 kW 660
Electric Heat - 108 kW 680
Electric Heat - 150 kW 700
Electric Heat - 200 kW 720
Electric Heat - 250 kW 740
Gas Heat - 1125 mbh 1,455
Hot Water Coil (2 rows x 14 ns per inch) 417
Steam Coil (1 rows x 10 ns per inch) 534
MISCELLANEOUS
Open Perimeter Curb 684
Enclosed Perimeter Curb 1,110
Airow Measurement Option 45
NOTES:
1. Sheet metal, air handling cabinet cooling only.
2. Includes all options.
3. Motor base is included in fan skid.
4. Filters only. Does not include the lter rack.
Weights represent approximate operating weights and have a +/- 10% accuracy. To calculate weight for a specic conguration, contact a
TempMaster sales representative.
Weight Data (Cont'd)
TABLE 6 – COMPONENT WEIGHTS (LBS) (CONT'D)
