TABLE 7 – COOLING PERFORMANCE DATA* – 120 TON MODEL (CONT’D)
AIR ENTERING
EVAPORATOR
COIL
OUTDOOR AMBIENT TEMPERATURE 95.0°F
ENTERING DRY BULB TEMPERATURE
CFM
WET
BULB (°F)
92.0°F 86.0°F 80.0°F 74.0°F 68.0°F
TMBH SMBH TMBH SMBH TMBH SMBH TMBH SMBH TMBH SMBH
32000
75 1638.0 1024.8 1636.5 852.0 1631.0 676.9
71 1531.5 1147.9 1530.8 976.6 1529.1 801.2 1529.1 620.1
67 1426.1 1267.7 1423.3 1096.8 1423.3 917.0 1423.3 740.4 1423.3 563.7
62 1394.2 1371.1 1332.3 1262.8 1332.3 1081.5 1332.3 906.7 1332.3 731.8
34500
75 1659.1 1069.3 1657.3 880.8 1653.1 690.6
71 1552.2 1203.4 1550.6 1016.3 1549.4 824.7 1549.4 628.7
67 1461.8 1315.7 1443.7 1147.6 1443.6 950.9 1443.6 759.7 1443.6 568.4
62 1433.4 1416.0 1364.8 1312.7 1344.1 1127.1 1344.1 936.6 1344.1 746.1
37000
75 1680.3 1113.8 1678.0 909.5 1675.3 704.3
71 1572.9 1259.0 1570.4 1056.0 1569.8 848.3 1569.8 637.3
67 1497.4 1363.7 1464.1 1198.5 1463.9 984.9 1463.9 779.0 1463.9 573.2
62 1472.6 1461.0 1397.3 1362.5 1355.9 1172.7 1355.9 966.5 1355.9 760.3
39500
75 1701.5 1158.3 1698.8 938.3 1697.4 717.9
71 1593.6 1314.5 1590.2 1095.6 1590.1 871.8 1590.1 645.8
67 1533.1 1411.7 1484.5 1249.3 1484.2 1018.8 1484.2 798.3 1484.2 577.9
62 1511.7 1505.9 1429.7 1412.4 1367.7 1218.2 1367.7 996.4 1367.7 774.6
42000
75 1722.6 1202.7 1719.5 967.0 1719.5 731.6
71 1614.3 1370.0 1610.0 1135.3 1610.4 895.3 1610.4 654.4
67 1568.8 1459.7 1504.9 1300.1 1504.5 1052.7 1504.5 817.7 1504.5 582.6
62 1550.9 1550.9 1462.2 1462.2 1379.5 1263.8 1379.5 1026.3 1379.5 788.8
44500
75 1734.8 1245.5 1731.9 994.2 1731.6 743.0
71 1634.0 1399.1 1622.2 1173.4 1622.5 916.8 1622.5 661.7
67 1589.7 1500.3 1517.7 1348.8 1516.9 1084.1 1516.9 835.1 1516.9 586.1
62 1569.5 1569.5 1461.7 1461.7 1421.8 1332.8 1410.8 1070.5 1399.7 808.3
47000
75 1746.9 1288.3 1744.2 1021.4 1743.7 754.4
71 1653.7 1428.2 1634.5 1211.6 1634.5 938.2 1634.5 668.9
67 1610.7 1541.0 1530.6 1397.5 1529.2 1115.4 1529.2 852.5 1529.2 589.5
62 1588.1 1588.1 1461.3 1461.3 1464.1 1401.8 1442.0 1114.8 1419.9 827.7
49500
75 1759.0 1331.1 1756.6 1048.5 1755.8 765.8
71 1673.3 1457.3 1646.7 1249.7 1646.6 959.7 1646.6 676.2
67 1631.6 1581.6 1543.4 1446.1 1541.6 1146.8 1541.6 869.9 1541.6 593.0
62 1606.7 1606.7 1460.8 1460.8 1506.4 1470.8 1473.3 1159.0 1440.1 847.2
52000
75 1771.1 1373.8 1768.9 1075.7 1767.9 777.2
71 1693.0 1486.4 1658.9 1287.8 1658.6 981.1 1658.6 683.4
67 1652.6 1622.3 1556.2 1494.8 1553.9 1178.1 1553.9 887.3 1553.9 596.4
62 1625.4 1625.4 1460.3 1460.3 1548.7 1539.8 1504.5 1203.2 1460.3 866.6
* Rated performance is at sea level. Cooling capacities are gross cooling capacity.
