TABLE 7 – COOLING PERFORMANCE DATA* – 120 TON MODEL (CONT’D)
AIR ENTERING
EVAPORATOR
COIL
OUTDOOR AMBIENT TEMPERATURE 105.0°F
ENTERING DRY BULB TEMPERATURE
CFM
WET
BULB (°F)
92.0°F 86.0°F 80.0°F 74.0°F 68.0°F
TMBH SMBH TMBH SMBH TMBH SMBH TMBH SMBH TMBH SMBH
32000
75 1566.4 997.6 1565.7 825.2 1562.9 651.4
71 1458.7 1117.9 1456.5 946.1 1455.6 771.1 1455.6 590.2
67 1378.5 1229.5 1359.3 1068.5 1359.3 888.8 1359.3 712.3 1359.3 535.8
62 1348.2 1325.4 1282.9 1214.4 1257.9 1045.7 1257.9 870.9 1257.9 696.2
34500
75 1583.1 1041.0 1582.6 853.1 1580.5 663.9
71 1478.3 1173.5 1476.2 986.3 1473.8 794.3 1473.8 598.5
67 1409.4 1276.3 1377.2 1118.7 1376.9 922.1 1376.9 731.0 1376.9 539.9
62 1384.4 1364.2 1312.9 1252.3 1273.0 1093.1 1272.7 904.8 1272.3 716.5
37000
75 1599.9 1084.5 1599.5 881.1 1598.2 676.4
71 1497.9 1229.1 1495.9 1026.4 1491.9 817.6 1491.9 606.8
67 1440.4 1323.2 1395.0 1168.9 1394.6 955.4 1394.6 749.7 1394.6 543.9
62 1420.5 1402.9 1342.9 1290.2 1288.2 1140.5 1287.4 938.6 1286.7 736.8
39500
75 1616.6 1127.9 1616.5 909.0 1615.8 688.9
71 1517.5 1284.7 1515.7 1066.6 1510.1 840.8 1510.1 615.0
67 1471.3 1370.1 1412.9 1219.1 1412.2 988.8 1412.2 768.4 1412.2 548.0
62 1456.6 1441.7 1372.9 1328.1 1303.3 1187.9 1302.2 972.5 1301.0 757.1
42000
75 1633.4 1171.3 1633.4 936.9 1633.4 701.4
71 1537.1 1340.3 1535.4 1106.7 1528.2 864.0 1528.2 623.3
67 1502.2 1417.0 1430.7 1269.3 1429.8 1022.1 1429.8 787.1 1429.8 552.0
62 1492.8 1480.5 1402.9 1366.0 1318.4 1235.3 1316.9 1006.4 1315.4 777.4
44500
75 1644.0 1213.9 1643.3 963.6 1643.2 712.4
71 1557.6 1366.3 1544.6 1144.1 1539.2 885.4 1539.2 630.5
67 1522.5 1453.2 1447.0 1313.5 1441.3 1053.5 1441.3 804.5 1441.3 555.5
62 1512.1 1502.9 1411.7 1384.1 1347.8 1276.6 1341.1 1034.5 1334.5 792.3
47000
75 1654.6 1256.5 1653.2 990.2 1653.1 723.5
71 1578.1 1392.4 1553.8 1181.6 1550.1 906.9 1550.1 637.7
67 1542.9 1489.5 1463.4 1357.8 1452.8 1084.9 1452.8 821.9 1452.8 559.0
62 1531.4 1525.2 1420.6 1402.1 1377.1 1318.0 1365.3 1062.6 1353.5 807.2
49500
75 1665.2 1299.1 1663.0 1016.9 1662.9 734.5
71 1598.6 1418.4 1563.0 1219.0 1561.1 928.3 1561.1 645.0
67 1563.2 1525.7 1479.7 1402.0 1464.3 1116.3 1464.3 839.4 1464.3 562.5
62 1550.7 1547.6 1429.4 1420.2 1406.5 1359.3 1389.5 1090.7 1372.6 822.1
52000
75 1675.8 1341.7 1672.9 1043.6 1672.8 745.5
71 1619.1 1444.4 1572.2 1256.4 1572.1 949.8 1572.1 652.2
67 1583.6 1562.0 1496.1 1446.2 1475.8 1147.7 1475.8 856.8 1475.8 566.0
62 1570.0 1570.0 1438.2 1438.2 1435.9 1400.7 1413.8 1118.9 1391.7 837.1
* Rated performance is at sea level. Cooling capacities are gross cooling capacity.
