27
TEMPMASTER
FORM TPM3-EG1 (518)
TABLE 7 – COOLING PERFORMANCE DATA* – 120 TON MODEL (CONT’D)
AIR ENTERING
EVAPORATOR
COIL
OUTDOOR AMBIENT TEMPERATURE 115.0°F
ENTERING DRY BULB TEMPERATURE
CFM
WET
BULB (°F)
92.0°F 86.0°F 80.0°F 74.0°F 68.0°F
TMBH SMBH TMBH SMBH TMBH SMBH TMBH SMBH TMBH SMBH
32000
75 1494.8 970.4 1494.8 798.4 1494.8 625.8
71 1386.0 1087.8 1382.1 915.6 1382.1 741.0 1382.1 560.4
67 1331.0 1191.2 1295.3 1040.1 1295.3 860.5 1295.3 684.2 1295.3 507.9
62 1302.2 1279.7 1233.4 1166.0 1183.5 1009.8 1183.5 835.2 1183.5 660.5
34500
75 1506.6 1012.7 1505.8 824.8 1504.4 636.1
71 1402.2 1138.6 1397.9 954.9 1397.9 763.9 1397.9 568.4
67 1356.6 1237.9 1310.8 1089.9 1310.8 893.5 1310.8 702.5 1310.8 511.6
62 1334.4 1316.0 1260.6 1205.2 1200.2 1058.5 1200.2 868.3 1200.2 678.1
37000
75 1518.3 1054.9 1516.8 851.1 1514.1 646.3
71 1418.3 1189.4 1413.7 994.3 1413.7 786.8 1413.7 576.3
67 1382.2 1284.7 1326.3 1139.6 1326.3 926.4 1326.3 720.8 1326.3 515.3
62 1366.7 1352.3 1287.7 1244.5 1216.9 1107.2 1216.9 901.5 1216.9 695.8
39500
75 1530.1 1097.2 1527.8 877.5 1523.7 656.6
71 1434.5 1240.2 1429.5 1033.6 1429.5 809.7 1429.5 584.3
67 1407.8 1331.4 1341.7 1189.4 1341.7 959.4 1341.7 739.1 1341.7 518.9
62 1398.9 1388.5 1314.9 1283.7 1233.6 1155.9 1233.6 934.6 1233.6 713.4
42000
75 1541.8 1139.4 1538.8 903.8 1533.3 666.8
71 1450.7 1291.0 1445.3 1072.9 1445.3 832.6 1445.3 592.2
67 1433.5 1378.2 1357.2 1239.1 1357.2 992.3 1357.2 757.5 1357.2 522.6
62 1431.1 1424.8 1342.0 1322.9 1250.3 1204.6 1250.3 967.8 1250.3 731.0
44500
75 1551.5 1181.9 1548.3 930.7 1544.4 678.6
71 1474.3 1318.8 1455.4 1110.9 1455.4 854.1 1455.4 599.4
67 1453.7 1409.1 1376.9 1278.7 1367.3 1023.5 1367.3 774.7 1367.3 525.9
62 1452.0 1447.2 1360.5 1346.2 1268.5 1218.8 1268.5 984.5 1268.5 750.1
47000
75 1561.1 1224.5 1557.9 957.6 1555.5 690.3
71 1498.0 1346.7 1465.4 1149.0 1465.4 875.5 1465.4 606.6
67 1474.0 1440.0 1396.6 1318.4 1377.4 1054.8 1377.4 791.9 1377.4 529.1
62 1472.9 1469.7 1379.1 1369.5 1286.7 1233.1 1286.7 1001.2 1286.7 769.3
49500
75 1570.8 1267.0 1567.4 984.5 1566.5 702.1
71 1521.6 1374.5 1475.5 1187.0 1475.5 897.0 1475.5 613.8
67 1494.2 1470.8 1416.2 1358.0 1387.5 1086.0 1387.5 809.2 1387.5 532.4
62 1493.8 1492.2 1397.6 1392.8 1304.8 1247.3 1304.8 1017.8 1304.8 788.4
52000
75 1580.4 1309.5 1576.9 1011.4 1577.6 713.8
71 1545.2 1402.4 1485.5 1225.0 1485.5 918.4 1485.5 620.9
67 1514.5 1501.7 1435.9 1397.6 1397.6 1117.2 1397.6 826.4 1397.6 535.6
62 1514.6 1514.6 1416.1 1416.1 1323.0 1261.5 1323.0 1034.5 1323.0 807.5
* Rated performance is at sea level. Cooling capacities are gross cooling capacity.
