TABLE 8 - COOLING PERFORMANCE DATA* – 130 TON MODEL
AIR ENTERING
EVAPORATOR
COIL
OUTDOOR AMBIENT TEMPERATURE 75.0°F
ENTERING DRY BULB TEMPERATURE
CFM
WET
BULB (°F)
92.0°F 86.0°F 80.0°F 74.0°F 68.0°F
TMBH SMBH TMBH SMBH TMBH SMBH TMBH SMBH TMBH SMBH
32000
75 1977.8 1208.4 1977.9 1009.4 1967.6 809.2
71 1850.5 1346.7 1851.3 1149.0 1842.1 947.3 1835.9 746.4
67 1731.2 1483.3 1731.7 1286.5 1731.0 1082.6 1726.7 887.3 1722.4 692.0
62 1657.6 1594.5 1592.0 1456.4 1587.7 1247.8 1589.1 1056.8 1590.5 865.7
34500
75 2005.0 1253.3 2004.1 1038.4 1995.8 823.8
71 1875.9 1401.6 1876.5 1188.5 1867.1 970.1 1860.9 755.3
67 1760.5 1526.4 1756.0 1335.2 1754.7 1115.2 1750.3 906.0 1745.9 696.8
62 1694.2 1639.2 1621.6 1496.9 1616.3 1297.4 1616.3 1090.8 1616.2 884.2
37000
75 2032.2 1298.1 2030.4 1067.4 2024.0 838.4
71 1901.3 1456.5 1901.7 1228.0 1892.2 993.0 1885.9 764.3
67 1789.7 1569.5 1780.3 1383.8 1778.3 1147.7 1773.9 924.7 1769.5 701.7
62 1730.7 1683.8 1651.3 1537.4 1644.9 1347.1 1643.4 1124.9 1642.0 902.7
39500
75 2059.4 1343.0 2056.6 1096.4 2052.2 852.9
71 1926.8 1511.5 1926.9 1267.5 1917.2 1015.8 1910.9 773.3
67 1819.0 1612.7 1804.6 1432.4 1802.0 1180.3 1797.5 943.4 1793.0 706.5
62 1767.3 1728.5 1680.9 1577.9 1673.4 1396.7 1670.6 1159.0 1667.8 921.3
42000
75 2086.7 1387.9 2082.8 1125.4 2080.4 867.5
71 1952.2 1566.4 1952.1 1307.0 1942.3 1038.6 1935.8 782.2
67 1848.3 1655.8 1828.9 1481.0 1825.7 1212.8 1821.1 962.1 1816.5 711.4
62 1803.8 1773.1 1710.6 1618.4 1702.0 1446.3 1697.8 1193.0 1693.5 939.8
44500
75 2104.2 1430.8 2099.6 1152.6 2100.6 880.7
71 1969.9 1619.9 1969.5 1345.0 1962.2 1062.0 1957.3 792.1
67 1878.3 1702.7 1845.7 1529.1 1842.2 1243.4 1835.6 978.6 1828.9 713.8
62 1838.0 1809.8 1742.1 1657.4 1713.6 1489.6 1709.1 1221.3 1704.6 953.0
47000
75 2121.8 1473.8 2116.5 1179.8 2120.7 894.0
71 1987.6 1673.3 1986.9 1383.0 1982.0 1085.4 1978.8 802.1
67 1908.4 1749.7 1862.6 1577.1 1858.8 1274.1 1850.1 995.1 1841.3 716.2
62 1872.2 1846.4 1773.6 1696.4 1725.2 1532.9 1720.4 1249.5 1715.7 966.1
49500
75 2139.4 1516.8 2133.4 1207.0 2140.8 907.3
71 2005.4 1726.8 2004.3 1421.0 2001.9 1108.9 2000.3 812.0
67 1938.5 1796.6 1879.4 1625.2 1875.3 1304.7 1864.5 1011.7 1853.7 718.6
62 1906.4 1883.1 1805.1 1735.4 1736.8 1576.2 1731.8 1277.8 1726.7 979.3
52000
75 2156.9 1559.8 2150.2 1234.2 2161.0 920.5
71 2023.1 1780.3 2021.8 1459.1 2021.8 1132.3 2021.8 821.9
67 1968.6 1843.5 1896.2 1673.3 1891.9 1335.4 1879.0 1028.2 1866.1 721.0
62 1940.5 1919.8 1836.6 1774.4 1748.4 1619.5 1743.1 1306.0 1737.8 992.5
* Rated performance is at sea level. Cooling capacities are gross cooling capacity.
