TEMPMASTER
FORM TPM3-EG1 (518)
TABLE 8 – COOLING PERFORMANCE DATA* – 130 TON MODEL (CONT’D)
AIR ENTERING
EVAPORATOR
COIL
OUTDOOR AMBIENT TEMPERATURE 85.0°F
ENTERING DRY BULB TEMPERATURE
CFM
WET
BULB (°F)
92.0°F 86.0°F 80.0°F 74.0°F 68.0°F
TMBH SMBH TMBH SMBH TMBH SMBH TMBH SMBH TMBH SMBH
32000
75 1905.1 1180.1 1902.7 980.0 1894.0 780.8
71 1780.5 1317.1 1779.5 1118.9 1775.1 919.1 1770.9 719.0
67 1663.2 1452.1 1665.0 1256.1 1664.6 1052.4 1661.7 857.7 1658.7 663.0
62 1601.2 1550.3 1530.8 1408.8 1527.7 1218.0 1528.0 1026.4 1528.3 834.9
34500
75 1930.8 1224.8 1928.0 1009.2 1920.2 795.0
71 1805.0 1372.1 1803.6 1158.3 1799.9 942.3 1796.1 728.5
67 1694.2 1493.7 1689.6 1305.3 1688.2 1085.3 1685.5 876.9 1682.9 668.5
62 1639.8 1594.6 1566.9 1454.4 1550.7 1265.4 1550.2 1058.5 1549.6 851.6
37000
75 1956.5 1269.5 1953.2 1038.3 1946.3 809.3
71 1829.5 1427.1 1827.8 1197.7 1824.7 965.5 1821.4 738.1
67 1725.2 1535.3 1714.2 1354.5 1711.8 1118.2 1709.4 896.1 1707.1 674.0
62 1678.3 1638.8 1603.0 1500.1 1573.7 1312.9 1572.3 1090.6 1570.9 868.4
39500
75 1982.2 1314.2 1978.4 1067.4 1972.4 823.5
71 1854.0 1482.1 1851.9 1237.2 1849.6 988.7 1846.6 747.6
67 1756.2 1576.9 1738.8 1403.7 1735.3 1151.1 1733.3 915.3 1731.2 679.6
62 1716.8 1683.1 1639.1 1545.8 1596.7 1360.3 1594.4 1122.7 1592.2 885.2
42000
75 2007.8 1358.9 2003.7 1096.5 1998.6 837.7
71 1878.6 1537.1 1876.0 1276.6 1874.4 1012.0 1871.9 757.1
67 1787.3 1618.5 1763.4 1452.9 1758.9 1184.0 1757.2 934.6 1755.4 685.1
62 1755.3 1727.4 1675.2 1591.4 1619.6 1407.7 1616.6 1154.9 1613.5 902.0
44500
75 2022.5 1401.3 2018.0 1123.3 2015.3 850.2
71 1893.8 1588.3 1891.2 1314.2 1889.3 1033.8 1886.7 764.9
67 1814.6 1667.0 1777.0 1500.1 1772.4 1213.9 1769.3 950.6 1766.1 687.2
62 1785.8 1760.8 1699.5 1624.4 1633.1 1452.3 1629.5 1184.3 1625.9 916.3
47000
75 2037.1 1443.6 2032.3 1150.1 2032.0 862.7
71 1908.9 1639.4 1906.4 1351.8 1904.3 1055.7 1901.5 772.6
67 1841.9 1715.5 1790.5 1547.2 1785.9 1243.9 1781.4 966.6 1776.9 689.4
62 1816.4 1794.3 1723.7 1657.5 1646.6 1496.9 1642.4 1213.7 1638.3 930.6
49500
75 2051.8 1486.0 2046.6 1176.8 2048.6 875.1
71 1924.1 1690.6 1921.6 1389.3 1919.3 1077.6 1916.3 780.3
67 1869.3 1764.1 1804.0 1594.4 1799.5 1273.8 1793.5 982.6 1787.6 691.5
62 1846.9 1827.8 1747.9 1690.5 1660.0 1541.4 1655.3 1243.1 1650.6 944.8
52000
75 2066.4 1528.4 2061.0 1203.6 2065.3 887.6
71 1939.3 1741.7 1936.8 1426.9 1934.2 1099.5 1931.1 788.1
67 1896.6 1812.6 1817.5 1641.5 1813.0 1303.7 1805.7 998.6 1798.4 693.6
62 1877.4 1861.2 1772.1 1723.5 1673.5 1586.0 1668.3 1272.6 1663.0 959.1
* Rated performance is at sea level. Cooling capacities are gross cooling capacity.
