TABLE 8 – COOLING PERFORMANCE DATA* – 130 TON MODEL (CONT’D)
AIR ENTERING
EVAPORATOR
COIL
OUTDOOR AMBIENT TEMPERATURE 95.0°F
ENTERING DRY BULB TEMPERATURE
CFM
WET
BULB (°F)
92.0°F 86.0°F 80.0°F 74.0°F 68.0°F
TMBH SMBH TMBH SMBH TMBH SMBH TMBH SMBH TMBH SMBH
32000
75 1832.5 1151.8 1827.6 950.6 1820.5 752.3
71 1710.4 1287.4 1707.7 1088.7 1708.1 890.9 1705.8 691.6
67 1595.2 1420.9 1598.3 1225.6 1598.2 1022.1 1596.6 828.0 1595.0 634.0
62 1544.9 1506.1 1469.7 1361.2 1467.8 1188.2 1466.9 996.1 1466.1 804.0
34500
75 1854.4 1195.7 1849.7 979.1 1843.1 765.9
71 1731.6 1341.7 1729.4 1127.8 1729.4 913.2 1727.4 700.2
67 1629.8 1443.8 1619.9 1216.4 1619.0 1054.4 1617.4 846.5 1615.8 638.6
62 1583.8 1549.1 1505.0 1406.8 1502.7 1241.7 1501.7 1034.6 1500.7 827.5
37000
75 1876.4 1239.7 1871.8 1007.6 1865.7 779.5
71 1752.9 1395.9 1751.0 1166.8 1750.6 935.5 1748.9 708.8
67 1664.4 1466.8 1641.5 1207.2 1639.8 1086.7 1638.2 865.0 1636.5 643.3
62 1622.8 1592.1 1540.3 1452.3 1537.7 1295.1 1536.5 1073.0 1535.3 851.0
39500
75 1898.3 1283.6 1893.9 1036.1 1888.3 793.0
71 1774.1 1450.1 1772.7 1205.9 1771.9 957.8 1770.4 717.4
67 1699.0 1489.8 1663.1 1198.0 1660.6 1119.0 1658.9 883.5 1657.2 648.0
62 1661.7 1635.2 1575.6 1497.9 1572.7 1348.6 1571.3 1111.5 1569.8 874.4
42000
75 1920.2 1327.5 1916.0 1064.7 1910.9 806.6
71 1795.3 1504.4 1794.3 1244.9 1793.1 980.1 1791.9 725.9
67 1733.6 1512.7 1684.7 1188.8 1681.3 1151.3 1679.7 902.0 1678.0 652.6
62 1700.7 1678.2 1610.9 1543.5 1607.6 1402.1 1606.0 1150.0 1604.4 897.9
44500
75 1934.2 1369.9 1929.9 1091.7 1925.6 818.6
71 1810.4 1554.1 1808.7 1282.4 1806.5 1001.7 1804.1 733.0
67 1756.4 1580.0 1698.2 1294.0 1694.5 1181.5 1692.8 918.8 1691.1 656.0
62 1729.1 1709.3 1635.0 1575.8 1605.4 1439.7 1602.9 1172.3 1600.4 904.9
47000
75 1948.1 1412.3 1943.8 1118.8 1940.3 830.6
71 1825.4 1603.8 1823.0 1319.8 1819.9 1023.4 1816.2 740.1
67 1779.1 1647.2 1711.7 1399.3 1707.7 1211.6 1706.0 935.5 1704.3 659.4
62 1757.5 1740.4 1659.2 1608.0 1603.1 1477.3 1599.7 1194.6 1596.3 911.8
49500
75 1962.0 1454.7 1957.8 1145.9 1955.0 842.7
71 1840.5 1653.5 1837.4 1357.3 1833.3 1045.0 1828.3 747.2
67 1801.9 1714.4 1725.3 1504.5 1720.9 1241.8 1719.2 952.3 1717.5 662.8
62 1785.9 1771.5 1683.3 1640.3 1600.8 1514.9 1596.6 1216.8 1592.3 918.8
52000
75 1976.0 1497.1 1971.7 1173.0 1969.7 854.7
71 1855.5 1703.2 1851.7 1394.8 1846.6 1066.6 1840.5 754.2
67 1824.7 1781.7 1738.8 1609.8 1734.1 1272.0 1732.4 969.1 1730.6 666.2
62 1814.3 1802.7 1707.5 1672.6 1598.6 1552.5 1593.4 1239.1 1588.2 925.7
* Rated performance is at sea level. Cooling capacities are gross cooling capacity.
