TABLE 8 – COOLING PERFORMANCE DATA* – 130 TON MODEL (CONT’D)
AIR ENTERING
EVAPORATOR
COIL
OUTDOOR AMBIENT TEMPERATURE 105.0°F
ENTERING DRY BULB TEMPERATURE
CFM
WET
BULB (°F)
92.0°F 86.0°F 80.0°F 74.0°F 68.0°F
TMBH SMBH TMBH SMBH TMBH SMBH TMBH SMBH TMBH SMBH
32000
75 1744.6 1118.6 1743.0 918.9 1735.1 720.3
71 1631.7 1255.2 1628.8 1056.5 1629.7 858.9 1627.5 659.8
67 1530.6 1392.3 1524.5 1193.1 1523.4 989.0 1521.9 795.1 1520.4 601.2
62 1488.4 1456.1 1417.7 1324.8 1399.8 1155.2 1398.9 963.1 1398.0 771.0
34500
75 1765.1 1162.5 1762.1 946.8 1755.4 733.4
71 1651.8 1309.5 1649.1 1095.4 1649.4 881.1 1646.4 667.8
67 1562.8 1430.2 1543.8 1241.1 1542.1 1020.9 1540.5 813.2 1539.0 605.4
62 1525.3 1496.7 1450.2 1367.3 1436.0 1209.7 1434.9 1002.6 1433.8 795.5
37000
75 1785.5 1206.3 1781.2 974.7 1775.6 746.6
71 1672.0 1363.9 1669.4 1134.4 1669.2 903.3 1665.3 675.8
67 1595.0 1468.1 1563.1 1289.2 1560.7 1052.9 1559.2 831.2 1557.6 609.6
62 1562.3 1537.4 1482.6 1409.8 1472.1 1264.1 1470.9 1042.0 1469.6 819.9
39500
75 1805.9 1250.1 1800.4 1002.6 1795.9 759.8
71 1692.1 1418.2 1689.7 1173.4 1688.9 925.6 1684.1 683.9
67 1627.2 1506.0 1582.3 1337.3 1579.4 1084.8 1577.8 849.3 1576.2 613.8
62 1599.3 1578.1 1515.1 1452.2 1508.3 1318.5 1506.9 1081.4 1505.5 844.3
42000
75 1826.3 1293.9 1819.5 1030.5 1816.2 772.9
71 1712.3 1472.5 1710.0 1212.3 1708.7 947.8 1703.0 691.9
67 1659.4 1544.0 1601.6 1385.3 1598.0 1116.7 1596.4 867.4 1594.8 618.0
62 1636.3 1618.7 1547.5 1494.7 1544.4 1373.0 1542.9 1120.9 1541.3 868.8
44500
75 1841.9 1337.3 1830.8 1057.1 1829.3 784.8
71 1733.2 1520.4 1721.4 1249.1 1719.2 968.7 1713.9 698.9
67 1687.0 1594.4 1612.3 1432.1 1608.3 1146.1 1606.8 883.4 1605.3 620.8
62 1668.9 1654.2 1569.2 1525.2 1540.9 1406.6 1538.9 1141.3 1537.0 876.0
47000
75 1857.6 1380.7 1842.2 1083.7 1842.3 796.6
71 1754.1 1568.2 1732.7 1286.0 1729.7 989.6 1724.8 705.9
67 1714.6 1644.9 1623.1 1478.8 1618.6 1175.5 1617.2 899.5 1615.8 623.6
62 1701.4 1689.7 1590.9 1555.8 1537.5 1440.2 1535.0 1161.7 1532.6 883.3
49500
75 1873.3 1424.1 1853.6 1110.3 1855.3 808.5
71 1775.0 1616.1 1744.1 1322.8 1740.2 1010.6 1735.7 712.9
67 1742.2 1695.3 1633.8 1525.6 1628.9 1204.9 1627.5 915.6 1626.2 626.3
62 1733.9 1725.2 1612.6 1586.3 1534.0 1473.9 1531.1 1182.2 1528.2 890.5
52000
75 1889.0 1467.5 1865.0 1136.9 1868.4 820.4
71 1795.9 1664.0 1755.4 1359.6 1750.7 1031.5 1746.6 719.9
67 1769.8 1745.8 1644.5 1572.3 1639.1 1234.2 1637.9 931.7 1636.7 629.1
62 1766.5 1760.6 1634.2 1616.8 1530.5 1507.5 1527.2 1202.6 1523.9 897.7
* Rated performance is at sea level. Cooling capacities are gross cooling capacity.
