TABLE 8 – COOLING PERFORMANCE DATA* – 130 TON MODEL (CONT’D)
AIR ENTERING
EVAPORATOR
COIL
OUTDOOR AMBIENT TEMPERATURE 115.0°F
ENTERING DRY BULB TEMPERATURE
CFM
WET
BULB (°F)
92.0°F 86.0°F 80.0°F 74.0°F 68.0°F
TMBH SMBH TMBH SMBH TMBH SMBH TMBH SMBH TMBH SMBH
32000
75 1656.8 1085.5 1658.4 887.2 1649.7 688.2
71 1552.9 1223.0 1549.9 1024.2 1551.3 826.8 1549.2 627.9
67 1466.0 1363.6 1450.7 1160.6 1448.6 955.9 1447.2 762.2 1445.7 568.5
62 1431.8 1406.0 1365.8 1288.4 1331.9 1122.2 1330.9 930.1 1329.8 738.0
34500
75 1672.4 1128.2 1673.3 914.1 1666.8 700.7
71 1569.8 1276.7 1568.5 1063.1 1568.8 848.7 1565.9 635.6
67 1496.1 1397.7 1467.7 1208.2 1465.3 987.6 1463.8 780.0 1462.4 572.5
62 1466.3 1443.8 1394.2 1326.7 1368.0 1177.1 1366.9 970.0 1365.7 762.9
37000
75 1687.9 1170.8 1688.2 941.1 1683.9 713.3
71 1586.7 1330.4 1587.2 1102.0 1586.3 870.5 1582.6 643.4
67 1526.2 1431.7 1484.6 1255.9 1482.0 1019.2 1480.5 797.8 1479.1 576.4
62 1500.7 1481.5 1422.5 1365.0 1404.1 1232.0 1402.9 1009.9 1401.6 787.8
39500
75 1703.4 1213.5 1703.1 968.0 1701.0 725.9
71 1603.7 1384.1 1605.9 1141.0 1603.9 892.4 1599.3 651.1
67 1556.3 1465.8 1501.6 1303.5 1498.7 1050.9 1497.2 815.7 1495.7 580.4
62 1535.1 1519.2 1450.9 1403.3 1440.2 1286.9 1438.9 1049.8 1437.5 812.7
42000
75 1718.9 1256.1 1718.0 994.9 1718.2 738.5
71 1620.6 1437.8 1624.5 1179.9 1621.4 914.3 1616.0 658.8
67 1586.4 1499.8 1518.5 1351.1 1515.4 1082.6 1513.9 833.5 1512.4 584.4
62 1569.5 1557.0 1479.3 1441.6 1476.3 1341.7 1474.9 1089.7 1473.4 837.6
44500
75 1739.7 1301.6 1728.0 1021.4 1730.4 750.4
71 1649.5 1484.5 1633.2 1216.0 1629.7 934.8 1625.1 665.5
67 1618.6 1552.3 1526.4 1397.1 1522.6 1111.1 1521.3 848.7 1520.0 586.3
62 1606.8 1597.4 1499.7 1471.4 1472.9 1371.9 1471.4 1108.8 1469.9 845.7
47000
75 1760.5 1347.1 1738.1 1047.8 1742.6 762.3
71 1678.4 1531.3 1641.8 1252.1 1638.1 955.3 1634.3 672.2
67 1650.7 1604.8 1534.4 1443.0 1529.8 1139.6 1528.7 863.9 1527.6 588.2
62 1644.1 1637.8 1520.1 1501.3 1469.4 1402.1 1467.9 1127.9 1466.5 853.7
49500
75 1781.2 1392.5 1748.2 1074.3 1754.8 774.1
71 1707.4 1578.0 1650.4 1288.3 1646.5 975.8 1643.5 678.8
67 1682.9 1657.4 1542.3 1488.9 1537.0 1168.0 1536.1 879.1 1535.2 590.1
62 1681.3 1678.2 1540.6 1531.1 1466.0 1432.3 1464.5 1147.0 1463.0 861.7
52000
75 1802.0 1438.0 1758.2 1100.8 1767.1 786.0
71 1736.3 1624.7 1659.1 1324.4 1654.8 996.3 1652.6 685.5
67 1715.0 1709.9 1550.3 1534.8 1544.2 1196.5 1543.5 894.2 1542.8 592.0
62 1718.6 1718.6 1561.0 1561.0 1462.5 1462.5 1461.0 1166.1 1459.6 869.7
* Rated performance is at sea level. Cooling capacities are gross cooling capacity.
