TEMPMASTER
FORM TPM3-EG1 (518)
TABLE 9 - COOLING PERFORMANCE DATA* – 150 TON MODEL
AIR ENTERING
EVAPORATOR
COIL
OUTDOOR AMBIENT TEMPERATURE 75.0°F
ENTERING DRY BULB TEMPERATURE
CFM
WET
BULB (°F)
92.0°F 86.0°F 80.0°F 74.0°F 68.0°F
TMBH SMBH TMBH SMBH TMBH SMBH TMBH SMBH TMBH SMBH
32000
75 2138.8 1312.9 2142.3 1080.7 2140.0 885.8
71 2001.9 1468.6 2003.0 1237.7 1999.2 1033.3 2000.4 814.4
67 1873.3 1630.0 1871.6 1406.0 1868.1 1184.3 1869.1 966.7 1870.0 749.0
62 1799.6 1746.3 1719.5 1595.0 1717.2 1369.3 1717.9 1160.6 1718.6 951.9
34500
75 2158.9 1349.3 2161.2 1105.0 2159.5 892.6
71 2021.5 1512.6 2023.0 1267.8 2018.7 1048.5 2019.9 819.8
67 1892.6 1659.2 1891.0 1446.3 1886.7 1207.0 1887.2 980.1 1887.8 753.3
62 1826.8 1778.7 1737.9 1620.2 1736.7 1403.3 1736.5 1183.5 1736.3 963.7
37000
75 2179.0 1385.8 2180.1 1129.4 2179.0 899.4
71 2041.1 1556.6 2043.0 1297.9 2038.2 1063.8 2039.4 825.3
67 1912.0 1688.5 1910.3 1486.5 1905.4 1229.7 1905.4 993.6 1905.5 757.5
62 1853.9 1811.1 1756.2 1645.4 1756.2 1437.3 1755.1 1206.4 1754.1 975.4
39500
75 2199.0 1422.2 2199.0 1153.7 2198.4 906.2
71 2060.6 1600.6 2062.9 1327.9 2057.6 1079.0 2058.9 830.7
67 1931.3 1717.7 1929.7 1526.8 1924.0 1252.4 1923.6 1007.1 1923.3 761.8
62 1881.1 1843.4 1774.6 1670.5 1775.7 1471.3 1773.7 1229.2 1771.8 987.2
42000
75 2219.1 1458.7 2217.9 1178.0 2217.9 913.0
71 2080.2 1644.7 2082.9 1358.0 2077.1 1094.2 2078.4 836.1
67 1950.7 1746.9 1949.0 1567.0 1942.6 1275.1 1941.8 1020.6 1941.0 766.0
62 1908.2 1875.8 1792.9 1695.7 1795.2 1505.3 1792.4 1252.1 1789.5 998.9
44500
75 2235.3 1490.0 2233.7 1197.0 2232.7 923.0
71 2095.3 1686.4 2096.1 1391.8 2091.7 1113.7 2092.9 877.0
67 1980.8 1787.9 1962.7 1602.0 1957.4 1301.8 1956.8 1035.3 1956.3 768.8
62 1939.8 1909.2 1827.1 1735.3 1809.0 1535.6 1805.6 1273.7 1802.2 1011.8
47000
75 2251.4 1521.3 2249.5 1216.0 2247.4 933.0
71 2110.4 1728.1 2109.4 1425.5 2106.3 1133.1 2107.4 918.0
67 2011.0 1828.8 1976.4 1636.9 1972.2 1328.6 1971.8 1050.1 1971.5 771.6
62 1971.4 1942.6 1861.2 1774.8 1822.8 1565.8 1818.9 1295.2 1814.9 1024.6
49500
75 2267.6 1552.7 2265.2 1235.0 2262.2 943.0
71 2125.4 1769.8 2122.6 1459.3 2120.8 1152.6 2121.9 958.9
67 2041.1 1869.8 1990.0 1671.9 1986.9 1355.3 1986.8 1064.8 1986.8 774.4
62 2002.9 1975.9 1895.4 1814.4 1836.6 1596.1 1832.1 1316.8 1827.6 1037.5
52000
75 2283.7 1584.0 2281.0 1254.0 2276.9 953.0
71 2140.5 1811.5 2135.8 1493.0 2135.4 1172.0 2136.5 999.9
67 2071.3 1910.7 2003.7 1706.8 2001.7 1382.0 2001.9 1079.6 2002.0 777.2
62 2034.5 2009.3 1929.5 1853.9 1850.4 1626.3 1845.4 1338.3 1840.3 1050.3
* Rated performance is at sea level. Cooling capacities are gross cooling capacity.
