TABLE 9 – COOLING PERFORMANCE DATA* – 150 TON MODEL (CONT’D)
AIR ENTERING
EVAPORATOR
COIL
OUTDOOR AMBIENT TEMPERATURE 85.0°F
ENTERING DRY BULB TEMPERATURE
CFM
WET
BULB (°F)
92.0°F 86.0°F 80.0°F 74.0°F 68.0°F
TMBH SMBH TMBH SMBH TMBH SMBH TMBH SMBH TMBH SMBH
32000
75 2052.4 1279.8 2053.3 1046.3 2050.4 832.4
71 1920.5 1442.5 1920.4 1214.4 1919.3 997.9 1918.7 780.3
67 1795.7 1596.2 1795.6 1364.6 1791.8 1148.0 1792.7 931.8 1793.5 715.5
62 1736.4 1693.6 1650.3 1539.6 1648.1 1335.7 1648.6 1126.2 1649.1 916.8
34500
75 2072.5 1313.2 2073.1 1068.9 2070.2 846.1
71 1940.0 1486.8 1939.3 1246.0 1938.8 1019.4 1938.5 788.9
67 1825.2 1641.6 1813.8 1406.2 1810.0 1172.5 1811.1 945.8 1812.1 719.1
62 1767.6 1733.3 1682.1 1592.7 1666.0 1374.3 1665.7 1151.4 1665.4 928.5
37000
75 2092.7 1346.7 2093.0 1091.6 2090.0 859.8
71 1959.6 1531.1 1958.2 1277.7 1958.4 1041.0 1958.3 797.5
67 1854.6 1686.9 1832.0 1447.8 1828.3 1197.0 1829.5 959.9 1830.8 722.8
62 1798.7 1773.0 1714.0 1645.8 1683.8 1412.9 1682.8 1176.5 1681.8 940.2
39500
75 2112.8 1380.2 2112.8 1114.3 2109.7 873.4
71 1979.1 1575.4 1977.0 1309.3 1978.0 1062.5 1978.1 806.1
67 1884.1 1732.3 1850.2 1489.4 1846.5 1221.4 1847.9 973.9 1849.4 726.4
62 1829.8 1812.7 1745.8 1698.9 1701.7 1451.4 1699.9 1201.7 1698.2 951.9
42000
75 2132.9 1413.7 2132.6 1137.0 2129.5 887.1
71 1998.6 1619.7 1995.9 1341.0 1997.6 1084.0 1997.9 814.7
67 1913.6 1777.7 1868.4 1531.0 1864.7 1245.9 1866.4 988.0 1868.0 730.0
62 1861.0 1852.4 1777.7 1752.0 1719.5 1490.0 1717.1 1226.8 1714.6 963.6
44500
75 2145.4 1447.7 2144.5 1158.1 2141.6 892.8
71 2010.7 1649.4 2007.5 1370.3 2008.6 1098.6 2008.9 835.9
67 1933.5 1799.2 1881.0 1568.2 1877.2 1271.9 1878.4 1002.5 1879.5 733.2
62 1887.1 1875.7 1798.0 1763.9 1731.7 1519.8 1728.8 1248.1 1725.9 976.4
47000
75 2157.9 1481.6 2156.4 1179.3 2153.7 898.6
71 2022.9 1679.2 2019.1 1399.5 2019.5 1113.3 2020.0 857.1
67 1953.4 1820.6 1893.6 1605.5 1889.7 1298.0 1890.4 1017.1 1891.0 736.3
62 1913.2 1899.0 1818.3 1775.7 1743.9 1549.6 1740.5 1269.4 1737.1 989.2
49500
75 2170.3 1515.6 2168.2 1200.4 2165.8 904.3
71 2035.0 1708.9 2030.7 1428.8 2030.5 1127.9 2031.1 878.2
67 1973.3 1842.1 1906.2 1642.7 1902.2 1324.0 1902.4 1031.7 1902.5 739.5
62 1939.4 1922.4 1838.6 1787.6 1756.0 1579.4 1752.2 1290.7 1748.4 1002.0
52000
75 2182.8 1549.6 2180.1 1221.5 2177.9 910.1
71 2047.2 1738.7 2042.4 1458.0 2041.4 1142.5 2042.1 899.4
67 1993.3 1863.6 1918.8 1679.9 1914.8 1350.0 1914.4 1046.3 1914.0 742.6
62 1965.5 1945.7 1858.9 1799.4 1768.2 1609.2 1763.9 1312.0 1759.6 1014.9
* Rated performance is at sea level. Cooling capacities are gross cooling capacity.
