TempMaster OmniElite - Page 46

TEMPMASTER
46
FORM TPM3-EG1 (518)
TABLE 23 - POWER SUPPLY VOLTAGE LIMITS
NOMINAL VOLTAGE POWER SUPPLY MINIMUM VOLTAGE MAXIMUM VOLTAGE
480 460V/3Ph/60Hz 414 506
600 575V/3Ph/60Hz 518 632
TABLE 24 - CONDENSER FAN MOTOR RLA
RLA EACH MOTOR
460V/3PH/60HZ 575V/3PH/60HZ
2.8 2.5
MODEL QUANTITY OF FANS 460V/3PH/60HZ 575V/3PH/60HZ
TMAL120–150 9 25.0 22.5
TABLE 22 - SUPPLY/EXHAUST/RETURN MOTOR DATA
ODP - HIGH EFFICIENCY TEFC - PREMIUM EFFICIENCY
MOTOR HP
460/3/60 575/3/60
MOTOR HP
460/3/60 575/3/60
FLA FLA FLA FLA
10 12.5 10 10 12 9.6
15 18 14.2 15 18.1 14.6
20 24 19.1 20 24 19.2
25 30 24.5 25 31 24
30 36 29 30 38 29
40 49 40 40 48 37
50 57 46 50 58 45
60 68 56 60 67.8 54.4
75 N/A N/A 75 N/A N/A
100 N/A N/A 100 N/A N/A
TABLE 27 - ELECTRICAL HEAT STAGES
120-150 TONS
80KW 108KW 150KW 200KW 250KW
AVAILABLE VOLTAGES
460V/3Ph/60Hz 3 3 4 6 7
575V/3Ph/60Hz 2 3 4 5 6
TABLE 25 - MISCELLANEOUS ELECTRICAL DATA
DESCRIPTION
NOMINAL VOLTAGE
460V 575V
AMPS AMPS
Control Transformer 1.5 kVA 3.3 2.6
Convenience Outlet 2.0 kVA 4.4 3.5
Gas Heat 1.5 kVA 3.3 2.6
TABLE 26 - ELECTRIC HEAT
KW
NOMINAL VOLTAGE
460V 575V
AMPS AMPS
80 96.2 77.0
108 120.3 92.6
150 192.5 154.0
200 240.6 192.5
250 288.7 230.9
NOTE:
1. Heaters will be sized as follows: 460V heaters rated at 480V,
575V heaters rated at 600V.
Electrical Data (Cont'd)
