FIGURE 1 - STANDARD CABINET ASSEMBLY
1. Modulating or staged gas heat
2. Condenser fans
3. Scroll compressors
4. Condenser
5. Advanced single package unit controller
6. Evaporator coil
7. Rain hoods
8. Exhaust/return fan
9. Economizer
10. Filters section
11. Double-wall construction
12. Double width, double inlet (DWDI) airfoil supply
fan
Outside Air
Exhaust Air
4
8
6
11
12
7
7
5
1
3
9
10
2
LD21646
