44|TS 45
02 VEHICLE
INFORMATION
Rev. 00 / 10.02.14
Icon Warning Text Error Explanation
Main Warning Panel
Lamp Status
Voice Status
CoolingWaterHot
Enginetemperatureishigh.Engineisoverheat-
ing.
WarningLampI(Red) Available
EngineCompartmentLidOpen Enginelidisopen.
WarningLampII
(Yellow)
Unavailable
OilPressureLow
Engineoilpressureislowortoolow.Lubricating
oillevelisaboveorbelowspecication.
WarningLampI(Red) Available
TransmissionTemperatureWarning
Transmissiontemperatureishigh.Transmissionis
overheating.
WarningLampII
(Yellow)
Unavailable
FaultGearbox Generalgearboxerror
WarningLampII
(Yellow)
Unavailable
Engine Seriousfailureonengine.
WarningLampI(Red)
WarningLampII
(Yellow)
Unavailable
EngineStopped
Enginestopwarning.Engineneedstobeser-
vicedattherstavailableopportunity.
WarningLampI(Red) Unavailable
2.3.2 Instrument Panel
