HW
O.A. Outdoor Air
SIDE SECTION
(Hot Water /
Chilled Water)
CW
SIDE SECTION
(Split System DX)
1. Return Air damper.
2. Outdoor air damper.
3. Supply air fan.
4. Hot water coil. Optional electric or
steam coil available.
5. Spring return mixed air damper actuator.
6. Filters.
7. Slab type DX cooling coil.
S.A. Supply Air
21.5"
8
7
21.5"
4
3
2
O.A.
1
6
5
R.A.
9
O.A.
8. Drain pan.
9. 2 pipe or 4 pipe (hot water coil can be
in the reheat position).
10. Heavy duty return air grille.
11. Hinged filter access panel.
12. Coil access panel.
FRONT ELEVATION
8
R.A. Return Air
S.A.
28"
S.A.
11
12
10
R.A.
93"
