SIDE SECTION
ISOMETRIC VIEW
(shown with left side access panel)
O.A. Outdoor Air
O.A.
1. Outdoor air damper.
2. Outdoor air filter.
3. Outdoor air fan.
4. Heavy duty return air grille or duct collar.
5. Outdoor air chilled water or DX coil.
6. Return air filter.
7. Primary chilled water or DX coil.
S.A. Supply Air
12
13
R.A.
Duct By
Others
O.A.
72
3
1
5
R.A.
4
6 8
93"
12" x 10"
Supply Air
Opening
8. Drain pan. Drain pan is removable when
option for bottom access panels is selected.
9. Electrical / control enclosure.
10. Optional Electric heater.
11. Supply air fan.
12. Mounting brackets (4 per unit).
13. Left or Right side hinged filter access panel.
14. Left or Right side hinged coil access panel.
14
12
S.A.
33"
R.A. Return Air
9
11
Duct By
Others
10
Suspension
Rods By
Others
S.A.
23"
